MC-8 Digital Controller
2-14

COMMAND MATRIX

The command matrix describes the commands that the remote control buttons perform when
each command bank is active.
1
Button
5
1
Deactivates standby mode and
6
activates the MC-8.
8
2
Activates standby mode and
deactivates the MC-8.
3 To g g l e s t h e F R O N T PA N E L
D I S P L AY
parameter between ALWAYS OFF
and its current setting.
To g g l e s
4
DISPLAY menu BACKGROUND
parameter between ON and
OFF.
To g g l e s
5
D I S P L AY
parameter between ON and
OFF.
Displays the Main Zone two-line
6
status for 2 seconds.
7 Activates an additional bank of commands that control the Main Zone. Refer to the previous page for
more information.
8 Activates an additional bank of commands that control Zone 2. Refer to the previous page for more
information.
Main Zone
Reserved for future possibilities.
Deactivates Zone 2.
Centers the AUDIO CONTROLS
m e n u S TAT U S m e n u Z O N E 2
parameter.
t h e O N - S C R E E N Sets the AUDIO CONTROLS
menu BASS, TREBLE and TILT EQ
parameters to +0.0dB.
t h e O N - S C R E E N Reserved for future possibilities.
m e n u S TAT U S
Displays the Zone 2 two-line
status for 2 seconds.
Zone 2 Shift
Reserved for future possibilities.
Deactivates the Main Zone.
Centers the AUDIO CONTROLS
B A L A N C E menu Main Zone BALANCE and
FADER parameters.
Deactivates the trigger output
connector labeled 1 when the
connector is configured for
remote operation.
Activates the trigger output
connector labeled 1 when the
connector is configured for
remote operation.
Toggles between opening and
closing the STATUS menu for the
current input source.
