- Page 1 Wind Up 100-4 Lighting Stand...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 25.07.2024, ID: 504973 (V3)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Operation..............................11 Technical specifications........................17 EU declaration of conformity......................18 Protecting the environment......................20 Wind Up 100-4 Lighting Stand... - Page 4 Wind Up 100-4 Lighting Stand...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This light stand is intended to be used for the stable mounting and height-adjustable posi‐ tioning of spotlights. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 8 Safety instructions CAUTION! Risk of injury due to tipping of the stand during loaded transport! If the stand is moved without having removed the installed devices, the stand may tip over and cause injuries and property damage. Remove the installed devices before transporting the stand. CAUTION! Risk of injury due to tipping of stand on an unsuitable ground! When the stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage.
- Page 9 Safety instructions NOTICE! Possible staining due to plasticiser in rubber feet! The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. Wind Up 100-4 Lighting Stand...
-
Page 10: Features
Features Features Special characteristics: Crank stand with four feet for greater stability Two telescopes, can be extended by means of a crank 3/8-inch mount (suitable for holding speakers with a 35 mm flange) Maximum load capacity: 110 kg Maximum height: 4.13 m Truss beam included Optional truss adapter: Item no. -
Page 11: Operation
Operation Operation Unpack and check carefully there is no transportation damage before using the product. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 12 Operation CAUTION! Risk of injury due to tipping of stand on an unsuitable ground! When the stand is installed on soft or uneven ground, the stand may tip over and cause injuries and property damage. Install the stand only on even and solid ground. CAUTION! Risk of injury due to tipping of the stand from excessive loading! In case of excessive loading, the stand might tip over, causing injury and property...
- Page 13 Operation CAUTION! Risk of injury due to inadequate minimum load during disassembly! If the stand is cranked down without bearing a minimum load, the steel rope can jam. The extension tube can sag unexpectedly and cause injury and property damage. Make sure that the stand is always loaded with the specified minimum load when it is cranked down.
- Page 14 Operation Setup & ö Before every use, make sure that the safety bolts are in the correct position and the union nuts have been tightened. The safety bolts must not turn during use. Wind Up 100-4 Lighting Stand...
- Page 15 Operation Loosen safety screw [1] on the lower carriage and unfold stand feet [2] until safety bolt [10] engages in the desired position in main tube [3]. Fold over fixing mechanism [B] as shown in the figure, then secure safety bolt [10] with spring split pin [A]. Secure the position with safety screw [1] on the lower carriage to which the four cross beams are attached.
- Page 16 Operation Disassembly Pull out spring split pin [A] of safety bolt [11] and fold fixing [B] in the opposite direction with the maximum angle in order to pull the safety bolt out of square tube [7]. Loosen safety screw [6] on the tube clamp of main tube [3] and crank square tube [7] all the way down with crank [8].
-
Page 17: Technical Specifications
Technical specifications Technical specifications Height, max. 4.13 m Mount type 3/8-inch mount; flange, Æ 35 mm Stand footprint, max. 2.13 m Load capacity, max. (with centric load) 110 kg Load capacity, min. (with centric load) 10 kg Transport dimension 1.95 m Weight 28.8 kg Truss beam dimensions... -
Page 18: Eu Declaration Of Conformity
EU declaration of conformity EU declaration of conformity Name and address of Thomann GmbH manufacturer / EU-AR Hans-Thomann-Straße 1 96138 Burgebrach Germany THIS DECLARATION OF CONFORMITY IS ISSUED UNDER THE SOLE RESPONSIBILITY OF: Name and address of Thomann GmbH manufacturer Hans-Thomann-Straße 1... - Page 19 EU declaration of conformity SIGNED FOR AND ON BEHALF OF: Burgebrach, 18 November 2021 Place and date of issue Wind Up 100-4 Lighting Stand...
-
Page 20: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 21 Notes Wind Up 100-4 Lighting Stand...
- Page 22 Notes Wind Up 100-4 Lighting Stand...
- Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
