- Page 1 SR-2012, SR-2018, SR-2024, SR-2008 studio rack assembly instructions...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 26.11.2019, ID: 129416, 129418, 129419, 351448...
-
Page 3: Table Of Contents
Table of contents Table of contents Safety instructions.......................................... 4 Scope of delivery..........................................5 Installation............................................7 Technical specifications......................................12 Protecting the environment....................................14 SR-2012, SR-2018, SR-2024, SR-2008... -
Page 4: Safety Instructions
Safety instructions Safety instructions DANGER! Danger for children Ensure that plastic bags, packaging, etc. are properly disposed of and are not in the reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the product. They could swallow the pieces and choke! Never let children play unattended with the product. -
Page 5: Scope Of Delivery
Scope of delivery Scope of delivery Before you assemble your rack, make sure the contents of package is complete according to the following list. 19-inch studio sack Millenium SR-2012 1 × baseplate, steel sheet 1 × cover plate, steel sheet 2 ×... - Page 6 Scope of delivery 19-inch studio rack Millenium SR-2024 1 × baseplate, steel sheet 1 × cover plate, steel sheet 2 × side panel, sheet steel with rack rails, guide rail for heavy duty angles and ventilation grilles 2 × caster 2 ×...
-
Page 7: Installation
Installation Installation Overview The following figure provides an overview of the positioning of the individual components. In addition to the Allen key supplied, you will need a suitable Phillips screwdriver and a soft pad for the assembly. SR-2012, SR-2018, SR-2024, SR-2008... - Page 8 Installation Assembly steps Turn the baseplate (1) so that you can screw the two side panels (2) in the baseplate (1) with each two Allen screws M6 × 20 (3) using the Allen key supplied. Use a soft padding to prevent damage to the mounting or housing surface. Place the assembled unit with the baseplate facing down on a suitable mounting surface.
- Page 9 Installation Place the cover plate (7) of the housing on the mounted unit and screw the cover plate in place with four Allen screws M6 × 20 (3) in the two side panels using the provided Allen wrench. Insert the four plastic caps (8) into the recesses on the cover plate. SR-2012, SR-2018, SR-2024, SR-2008...
- Page 10 Installation Place the assembled unit with the cover plate facing down on a suitable mounting surface. Use a soft padding to prevent damage to the mounting or housing surface. Mount the two casters (10) and the two locking casters (9) or alternatively the four height-adjustable feet (11) to the base plate.
- Page 11 Installation To install the equipment into the studio rack, screw it in the rack rails with a Phillips screwdriver using the Phillips screws M6 × 20 (13), M6 cage nuts (14), and plastic washers (15) as illustrated. SR-2012, SR-2018, SR-2024, SR-2008...
-
Page 12: Technical Specifications
Technical specifications Technical specifications 19-inch studio rack SR-2012 Construction type Solid sheet steel construction with rack rails, guide rail for heavy duty angles and ventilation grilles Item no. 129416 Installation width 19 inch Rack units (RU) Installation depth max. 400 mm Power handling max. - Page 13 Technical specifications 19-inch studio rack SR-2024 Construction type Solid sheet steel construction with rack rails, guide rail for heavy duty angles and ventilation grilles Item no. 129419 Installation width 19 inch Rack units (RU) Installation depth max. 400 mm Power handling max.
-
Page 14: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging material For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 16 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
