Fortinet FortiGate FG-80F-BYPASS Quick Start Manual page 6

Front - FG 80F-POE Series
- PoE
PWR
1
FortiGate
1
LOGO
Green: The device is on
Off: The device is off
2
Green: Both power supplies are functioning
PWR
Amber: One power supply is functioning
Off: Power is off
Green: Operating normally; BLE is off
STATUS
Flashing
Flashing Amber:
Green: Operating in an HA cluster
HA
Amber: HA failover
Off: Not in an HA cluster
3 Flashing
SFP/WAN
(WAN & SFP Off: No link established
are Shared Ports)
Red: Providing Max PoE Power, 96W
4
MAX PoE
Off: PoE power available
5
Ports
Green: PoE power on
PoE
Off: PoE power off
Flashing
LINK/ACT
Off: No link established
BLE/RESET Activates BLE management or restores to factory default
10
PoE
STATUS SFP1 WAN1 1 2 3 4 5 6 A B
PoE
LINK/ACT
HA SFP2 WAN2 MAX
PoE
2 3 4 5
Green: Booting up
BLE is on
Green: 1000M/100M/10M data activity
Green: 1000M/100M/10M data activity
CONSOLE
BLE / RESET
1
6
1
Grounding Screw additional protective earth connection, reserved for
applications where a permanent local connection of protective earth is required
2
Console (RJ-45) CLI management computer interface
USB (USB A) USB 3.0 server port
3
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
4
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
5
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
6
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
7 Power Input 54V DC 2.78A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
Back - FG 80F-POE Series
1
SFP 1 – shared – WAN 1
USB SFP 2 – shared – WAN 2 2
2 3 4
English
3 5 A
4 6 B 54V 54V
5 6 7
11
