QuickStart Guide
FG-50G-SFP-QSG-20240423.indd 1
FG-50G-SFP-QSG-20240423.indd 1
FortiGate 50G SFP
FG-50G-SFP, FG-51G-SFP
4/23/2024 7:15:43 PM
4/23/2024 7:15:43 PM

Advertisement

loading
Need help?

Need help?

Do you have a question about the FortiGate 50G SFP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fortinet FortiGate 50G SFP

  • Page 1 QuickStart Guide FortiGate 50G SFP FG-50G-SFP, FG-51G-SFP FG-50G-SFP-QSG-20240423.indd 1 FG-50G-SFP-QSG-20240423.indd 1 4/23/2024 7:15:43 PM 4/23/2024 7:15:43 PM...
  • Page 2 FortiGate Cloud Experience simplified cloud provisioning, security analytics, remote access, hosted log retention and reporting at https://fortigate.forticloud.com FortiExplorer Go Rapidly provision, deploy and manage your Fortinet Security Fabric Platform, free on iOS and Android: https://docs.fortinet.com/product/fortiexplorer-go/ FG-50G-SFP-QSG-20240423.indd 2 FG-50G-SFP-QSG-20240423.indd 2 4/23/2024 7:15:44 PM...
  • Page 3: Package Contents

    Package Contents FortiGate 50G SFP FG-50G-SFP 1x FortiGate Device 1x QuickStart Guide 3x AC Adapter Plugs 1x DC Power Adapter (US, EU, UK) 1x Ethernet Cable 2x SFP Transceivers FG-50G-SFP-QSG-20240423.indd 3 FG-50G-SFP-QSG-20240423.indd 3 4/23/2024 7:15:45 PM 4/23/2024 7:15:45 PM...
  • Page 4 Setup FortiExplorer Go Install Enable Follow the on-screen FortiExplorer Go Bluetooth instructions Port 1 If Static IP: 192.168.1.1/24 Ethernet Cable FG-50G-SFP-QSG-20240423.indd 4 FG-50G-SFP-QSG-20240423.indd 4 4/23/2024 7:15:45 PM 4/23/2024 7:15:45 PM...
  • Page 5 None (available for purchase) Flow Control: None Console Port FortiGate Cloud Login to https://fortigate.forticloud.com using your Fortinet Credentials, then click Add FortiGate and enter the Cloudkey Internet Ethernet Cable WAN port FG-50G-SFP-QSG-20240423.indd 5 FG-50G-SFP-QSG-20240423.indd 5 4/23/2024 7:15:45 PM 4/23/2024 7:15:45 PM...
  • Page 6 Front FG-50G-SFP FortiGate 50G SFP PWR STATUS BLE/RESET Signed Firmware BLE / RESET Press to enable BLE; press and hold for system reset Blue: BLE connected Flashing Blue: BLE in discovery Off: BLE not connected Signed Firmware BIOS Security Level Controlled by Signed Firmware Switch, see Admin Guide at https://docs.fortinet.com...
  • Page 7 LINK/ACT SPEED Green: Power detected Off: Power not detected STATUS Green: Operating normally Green: Booting up Flashing Off: Device is off Green: HA enabled (normal) Amber: HA enabled (failover) Off: HA disabled Ethernet Ports LINK/ACT SPEED Green: Connected Green: 1 Gbps Green: Data activity Amber: 100 Mbps Flashing...
  • Page 8 Rear FG-50G-SFP Signed Firmware Power Input 12V DC, 100-240V AC, 50/60Hz adapter USB 3.0 Port (USB-A) CONSOLE Port (RJ-45) CLI management Signed Firmware Switch FG-50G-SFP-QSG-20240423.indd 8 FG-50G-SFP-QSG-20240423.indd 8 4/23/2024 7:15:46 PM 4/23/2024 7:15:46 PM...
  • Page 9 SFP Port (SFP) Ports (5x RJ-45) WAN, A – FortiLink, 3, 2, 1 FG-50G-SFP-QSG-20240423.indd 9 FG-50G-SFP-QSG-20240423.indd 9 4/23/2024 7:15:46 PM 4/23/2024 7:15:46 PM...
  • Page 10: Cautions And Warnings

    Cautions and Warnings Environmental specifications Ambient operating temperature: 0°C to 40°C Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude) Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Battery –...
  • Page 11: Regulatory Notices

    Regulatory Notices Federal Communication Commission (FCC) – USA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 12: Voluntary Control Council For Interference (Vcci) - Japan

    EU or countries that have implemented the EU Directives and/or spectrum regulation. Any Fortinet products not obtained directly from Fortinet or Fortinet’s authorized partners may not comply with EU Directives and Fortinet makes no assurances for such products.
  • Page 13: Bureau Of Standards Metrology And Inspection (Bsmi) - Taiwan

    Bureau of Standards Metrology and Inspection (BSMI) – Taiwan The presence conditions of the restricted substance (BSMI RoHS table) are available at the link below: 限用物質含有情況表 (RoHS Table) 請到以下 網址下載: https://www.fortinet.com/bsmi 請仔細閱讀以下說明 本設備勿置於潮濕處。 連接至電源前,請先檢查電壓。 當設備不用時,請將所有電源線拔除,避免電壓不穩而造成傷害。 勿將任何液體濺入設備中,避免線路短路。 基於安全理由,只有受到專業訓練的從業人員,才可以打開本設備。 請勿自行調整或修理已通電的設備,以確保您的安全。 如不小心受傷,請立刻找急救人員給予您適當的救護,千萬別因傷勢輕微而忽略自己的傷勢。 請依照台灣法規處置電池。 若不正確替換電池可能導致爆炸危險,替換電池時,請使用設備生產商推薦使用的電池。 請勿拆卸、刺穿或以其他方式損壞電池。 雷射設備非用戶維修設備,請與生產商聯繫維修事宜。 英屬蓋曼群島商防特網股份有限公司台灣分公司 地址:台北市內湖區行愛路176號2樓 電話:(02) 27961666 National Telecommunications Commission (NCC) – Taiwan NCC警語 取得審驗證明之低功率射頻器材,非經核准,公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射頻器材之 使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無干擾時方得繼續使用。前述合法通信,指依電信管理法規 定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 UK Conformity Assessed (UKCA) – United Kingdom...
  • Page 14 FG-50G-SFP-QSG-20240423.indd 14 FG-50G-SFP-QSG-20240423.indd 14 4/23/2024 7:15:46 PM 4/23/2024 7:15:46 PM...
  • Page 15 FG-50G-SFP-QSG-20240423.indd 15 FG-50G-SFP-QSG-20240423.indd 15 4/23/2024 7:15:46 PM 4/23/2024 7:15:46 PM...
  • Page 16 Copyright © 2024 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners.
