- Page 1 AGRIMATE ELECTRIC SPRAYER - Double Pump AM-BSDP-20MS+ Before Operating this machine please read instructions Manual carefully Desclaimer: Due to Constatnt upgradation, features & Specifications are subject to change without prior notice...
- Page 2 Dear Sir/Madam, Thank you for choosing Agrimate product. You are the proud owner of high technology and durable machine. Trust that our franchisee/dealer installed the product and explained you about the usage and service instructions. Please visit our authorised dealer for you future requirement of our other equipments, genuine spares, accessories and service.
-
Page 3: Maintenance
MAINTENANCE Each time after using this sprayer, it must be charged to maintain inside power and to avoid short working life. When doing change or discharge, please assure that you have switched off the power to avoid to wasting electricity. After using sprayer. - Page 4 SL NO PART NO PHOTOS DESCRIPTION AM-BSDP-20MS-01 Tank cap AM-BSDP-20MS-02 Strainer Tank AM-BSDP-20MS-03 AM-BSDP-20MS-04 Backrest AM-BSDP-20MS-05 Hose AM-BSDP-20MS-06 Inner filter AM-BSDP-20MS-07 Elbow AM-BSDP-20MS-08 Double pump...
- Page 5 SL NO PART NO PHOTO DESCRIPTION AM-BSDP-20MS-9.1 Indian 8 holes nozzle AM-BSDP-20MS-9.2 Indian single nozzle AM-BSDP-20MS-9.3 Indian 4 holes nozzle AM-BSDP-20MS-10 Gun handle AM-BSDP-20MS-11 Trigger AM-BSDP-20MS-12 Indian lance 1 brass end 2 plastic end AM-BSDP-20MS-13 Spraying gun-Zinc alloy AM-BSDP-20MS-14 2.0A Charger...
- Page 6 SL NO PART NO PHOTOS DESCRIPTION AM-BSDP-20MS-15 Regulator AM-BSDP-20MS-16 Double switch with wire AM-BSDP-20MS-17 Charging socket with wire AM-BSDP-20MS-18 Volt meter with wire AM-BSDP-20MS-19 12V/14AH battery real is 12AH AM-BSDP-20MS-20 Bottom plate AM-BSDP-20MS-21 Car belt AM-BSDP-20MS-22 Lance clip AM-BSDP-20MS-23 Battery clip...
-
Page 7: Inspection And Maintenance
INSPECTION & MAINTENANCE For safety, make sure the machine is cleaned every three-months. Before working, make sure to inspect the filter and the nozzle, and ensure there is no impurity. After working, make sure there is no water in the pump and the hose. If the machine needs to be repaired in the guarantee period, please return the machine to the shop. -
Page 8: Warranty Card
WARRANTY CARD CUSTOMER COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE DATE OF DELIVERY PURCHASERS NAME & ADDRESS CUSTOMER SIGN INVOICE/DN NO. PRODUCT SERIAL NO. PRODUCT NAME I/Will accept the terms and conditions of warranty as in the warranty card DEALERS COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE... - Page 9 1.LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty Card duly filled and stamped by authorized dealer together with the original purchase document.
- Page 10 1st service coupon ISO 9001 : 2015 CERTIFIED COMPANY FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER SERIAL NUMBER MODEL SERVICE NO. PURCHASE BILL NO. DATE PDI DATE OPERATIONS DEALERS OFFICE SEAL 1. Check and test the fuel mixture 2. check and clean the air filter 3.Check , clean and adjust the spark plug 4.
- Page 11 DONTS attempting to use the equipments. Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before trousers and jackets while operating potentially dangerous machines 2. It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, 3.
- Page 12 NO. 1 CHOICE OF FARMERS SINCE 1999 RATNAGIRI IMPEX PVT., LTD., Annapurna House, #1 / 1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore - 560 026 Missed Call : 7393 938 938 Email: ask@agrimart.in...
