Extension cable
Cable tie
Extension cable
Cable tie
Intermec EasyLAN Interface Kit Installation Instructions
RJ-45
connector
EasyCoder PF2/4i-series printer
RJ-45
connector
EasyCoder PM4i printer
Chapter 1 — Physical Installation
Light guide
#T20 Torx screw
and spacer
EasyLAN interface
board
Light guide
#T20 Torx screw
and spacer
EasyLAN interface
board
5
