2 PRODUCT DESCRIPTION

2.1 Overview
RAL SmearBox is intented for use by medical professionals, in a laboratory environment, to
®
make blood smear specimens (spread a small amount of blood to make a monolayer of cells)
before examination under microscope.
2.2 RAL SmearBox features
®
The main features of the product are:
- Highly repeatable spreading quality
- Easy to use
- Safe to use
- Small size requiring small space
REF.: 22019-V07
Revised: 2022-04-07
2 Product description
12
13

2.3 Quick tour

Follow this quick tour of major features and important repair steps when servicing a RAL
SmearBox. Please see the specific repair sections to obtain full details on servicing specific
parts.
Front view
1 Lid (open position)
2 Slide spreader receptacle
3 Blood tube receptacle
4 Control panel
5 Glass slide receptacle
6 Disposable waste bin receptacle
13
2 Product description
®
REF.: 22019-V07
