3. Insert a bin in the associated receptacle
Click here to watch a video explaining how the waste bin works.
Do not launch a cycle without a bin placer in the receptacle or the receptacle
could be contaminated.
2.5 Identification
The model name and serial number are listed on nominal plate located at the rear of the
spreader. The serial number contains information about production code, date of production
and the spreader production number. The label also identifies power rating and regulatory
information.
REF.: 22019-V07
Revised: 2022-04-07
2 Product description
18

2.6 Technical specifications

RAL SmearBox - Technical datasheet
®
Weight
Height
Width
Depth
Noise level
Physical
characteristics Pace
Capacity
Supply voltage
Electrical
Operating voltage
characteristics
Overvoltage category
Power supply
Connections
USB flash drive port
Operating temperature
Moisture in use
Storage and transport
temperature
Environmental
limits
Storage and transport
moisture
Maximum altitude
Maximum pollution levels
Maximum
On
Power
consumption
Idle
Off
19
2 Product description
2,2 kg (4,85 LBS) without power supply
233 mm
235 mm
238 mm
50 db(A)
1'30 per smear
1 blood tube
1 microscope slide
1 RAL ® SmearBox Slide Spreader
48 RAL ® SmearBox Slide Spreaders in the bin
100-240V AC, 50/60 Hz, 2,5 A
24V DC, 2,5 A, 60W maximum
II
1
1
15°C to 32,5°C (59° to 90,5°F)
10% to 70%
-20°C to 60°C (-4° to 104°F)
10% to 70%
2 000 m
2
45W
5W
0W
0W
