- Page 1 Dual PAL or NTSC Multi-system RGB Converter with 12V Relay #236 Switch Operation Manual...
- Page 2 Introduction This unit allows the user to upgrade their car's LCD screen or navigation system to allow the viewing of video such as DVD's, TV, Playstation 2, etc. This Plug & Play converter also has the capability to view a reverse camera on your car's LCD screen.
- Page 3 Operation Controls and Functions Front Panel 1. RGBs/RGsB Switch- This button is used to select between RGBs or RGsB (Sync On Green). 2. 9-Pin D Female Connector- RGB Out: DB9 Pin configuration 1) Gray: Pin 1-GND 7) Purple: Pin 7- Blue out 2) Brown: Pin 2- Sync of source 1 8) Orange: Pin 8- Blue in from source 1 3) Red: Pin 3- RED out.
- Page 4 3. Toggle switch to switch between convert and RGB bypass- Procedure Output Select Open Convert Short Bypass Procedure -If 12V Trigger is activated then reverse camera (Video2) takes priority over both Video1 and Navigation. -If 12V Trigger is not activated and the Toggle switch is ON, then DVD’s (Video 1) is activated.
- Page 5 V2 input: This input is selected and converted to RGB out when the control wires is set to high (12Volt) regardless of the setting of the toggle switch. It is suitable for reverse camera input. 3. Relay (through 12V/GND control wires): When this control wire is connected to 12Volt it forces Video 2 input to be converted to RGB output, regardless of the setting of the toggle switch.
- Page 6 Wiring Diagram The Installer be required to know which wire is which from the Car navigation CPU in order to connect them to the converter. Please refer to 9-Pin D Female Connector Table. Specifications...
