Summary of Contents for Lincoln PILE DRIVER III D Series
- Page 1 Model Nos. 2321, 2327, 2329, 2354, 2369, 84922 PILE DRIVER III PUMP ASSEMBLY ® Series “D” - A50 - 77G April 2003 Form 422829 Section Page...
-
Page 2: Product Specifications
PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 TABLE OF CONTENTS GLAND PACKING DESIGN* SAFETY Do not fill the lube well to full capacity, as the reciprocat- ing movement of the pump may draw fluid into the airmotor. -
Page 3: Pump Assembly
PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 Airmotor Dimension "A" Pump Tube Airmotor [mm.] w/ AirBrake 86810 94810 42-5/8 [1083] 84808 94808 84922 84806 94806 84804 94804 43-1/2 [1105] 84803 Page Number - 3 Form 422829... -
Page 4: Operating Precautions
PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 NOTE: SERVICING. ATTACHING AIRMOTOR TO PUMPTUBE* PREVENT STATIC SPARKING DO NOT allow pump to operate when out of material. OPERATING PRECAUTIONS HEED ALL WARNINGS. Page Number - 4 Form 422829... -
Page 5: Pump Priming
PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 PUMP PRIMING NOTE: OUTLET POSITION ADJUSTMENT DISASSEMBLY PROCEDURE Tools Required Used on Item # Procedure Page Number - 5 Form 422829... - Page 6 PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 NOTE: Install wipers (Item 5) and U-Cups (Items 8 & 18) in direction shown in enlarged views. Page Number - 6 Form 422829...
-
Page 7: Parts List
PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 PARTS LIST Item Part Description Qty. Number Bolt Connector (7/8" hex) 236225 Coupling Nut (1-1/4" hex) 237051 Gland Nut (3-1/8" flats) 272832 Spacer 239951 Wiper 239950 Bushing 272831 O-ring (polyurethane) # * ^... -
Page 8: Troubleshooting
PILE DRIVER III PUMP ASSEMBLY ® Models 2321, 2327, 2329, 2354, 2369, 84922 TROUBLESHOOTING Problem Possible Cause Solution Pump does not operate. Restricted or inadequate air supply. Check air supply pressure and air hose diameter (see Airmotor manual for minimum air supply hose diameter). Obstructed material output.
