Triton ARGO-FT Upgrade Instructions

Mainboard module x3 to x4 upgrade
Hide thumbs Also See for ARGO-FT:
1
2
3
4
5

Advertisement

Quick Links

Download this manual
ARGO-FT X3 to X4 Upgrade Instructions
©2024 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline,
Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC.  e third
party trademarks that may be identi ed herein are the trademark of their respective owners. Triton disclaims any
affi liation, connection, or association between its products and services, and those of the respective trademark
owners, or any sponsorship or approval of its products and services by such trademark owners.
07103-08617 Rev A

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARGO-FT and is the answer not in the manual?

Questions and answers

Related Manuals for Triton ARGO-FT

Summary of Contents for Triton ARGO-FT

  • Page 1 ©2024 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline, Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC.  e third party trademarks that may be identi ed herein are the trademark of their respective owners. Triton disclaims any affi...
  • Page 2 1 (866) 787-4866 (opt 3) or +1 (228) 575-3100 (opt 3)   is guide covers converting the Main Board Module and display cable from X3 to X4, for the ARGO-FT ATMs.   is manual applies to all service personnel involved in installing, converting, or upgrading hardware on Triton ATMs nationwide and abroad.
  • Page 3 ARGO-FT M R P 1. Wear an Electrostatic Discharge device, wrist strap or gloves, grounded to ATM chassis before continuing. 2. Login to ATM. Navigate menu to Management Functions > System Parameters (5) > Shut Down the Terminal (4). Press Enter will verify to exit the program. When the ‘shutdown’ image appears on screen, on the power supply, press the switch to the OFF (0) position.
  • Page 4 14. An Incorrectly nger placement on the center of the Module will damage the memory components. 15. Visually inspect the Module is seated properly in the socket.  e clamps, ovals, hold the Module in the socket. ORANGE arrows, equal height of gold pins shown. 07103-08617 Rev A Triton Systems ©...
  • Page 5 19. If the Module does not easily seat in the socket, remove the module and insert again. 20. Install Baseboard cover. 21. On the power supply, press the power switch to ON (0).  e Power-On-Self-Test screen displays Triton CE Application Version 5.0 or higher.
