ARGO FT MODEM KIT
INSTALLATION MANUAL
©2019 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline,
Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC. The third party
trademarks that may be identified herein are the trademark of their respective owners. Triton disclaims any affili-
ation, connection, or association between its products and services, and those of the respective trademark owners,
or any sponsorship or approval of its products and services by such trademark owners.
TDN 07103-00354

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARGO FT MODEM KIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triton ARGO FT MODEM KIT

Summary of Contents for Triton ARGO FT MODEM KIT

  • Page 1 ©2019 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline, Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC. The third party trademarks that may be identified herein are the trademark of their respective owners. Triton disclaims any affili- ation, connection, or association between its products and services, and those of the respective trademark owners, or any sponsorship or approval of its products and services by such trademark owners.

  • Page 2: Revision History

    Date Description Original 9/27/2019 ARGO FT Modem Installation Kit 1032350 Contact Information Triton© Headquarters and Manufacturing Plant 21405 B Street Long Beach, MS 39560 USA 1 (866) 787-4866 (228) 575-3101 (fax) techsvs@triton.com 1 (800) 259-6672 (opt 4) Triton Systems ©...

  • Page 3: Parts Supplied

    ARGO FT Modem Installation Kit 06100-00148 parts supplied Items Description Quantity 56K Modem Assembly RJ11 Phone Cable, 12 ft Right Angle B, USB Printer Cable Ferrite Clamp-on; 280 ohm@100 MHz, 17.3mm outer diameter x 36.2mm length, 5.1 mm inner diameter core Triton Systems ©...

  • Page 4: Installation Procedure

    6. Locate the empty modem shelf above the fan. 7. Obtain the modem from the kit. Align the slots on the back of the modem with pins on the shelf. Slide the modem onto the shelf until it clicks to the pins. Triton Systems ©...
  • Page 5 9. Route the cable under the fan and connect the USB connector to the mainboard’s port labeled MDM. 10. Open the cable hanger clip and insert the USB cable. Close the cable hanger over the cables as shown. Triton Systems ©...
  • Page 6 22. For the Walk-Up ATM, continue to step 13. 13. For the Walk-Up ATM, route the phone cable through the two clips shown in the left image. Place the re- maining cable into the opening of the bottom cabinet shown in the right image. Triton Systems ©...
  • Page 7 ATM. Connect the cable to the wall phone port. 17. For the Drive-Up ATM with the deep cabinet, route the cable through the two clips as shown in the left im- age and the third clip in the right image. Triton Systems ©...
  • Page 8 ATM. Connect the cable to the wall phone port. 22. For the Drive-Up ATM with the shallow cabinet, route the cable through the two clips shown in the left im- age. Triton Systems ©...
  • Page 9 26. If routing to the opposite side of cabinet, insert the cable into the two clips on the back wall. Route the phone cable through the opening at the bottom corner of the ATM. Connect the cable to the wall phone port. Triton Systems ©...
  • Page 10 5. Select Message Format. This option specifies the content and structure of the message that passes between the terminal and the host processor during a transaction. 6. Use the Up or Down button to highlight TDL. Press the Select button to check the box. Press the Save and Return button. Triton Systems ©...
  • Page 11 The Left and Right buttons moves the cursor one position per each click. The Backspace button deletes the character to the left of the cursor. Enter a valid backup phone number. Press the Enter and Return button. Triton Systems ©...
  • Page 12 11. Select Predial. This option allows the terminal to dial out to the host processor and establish a connection as soon as the customer swipes their card. 12. Select Enable Communication Header, if the host processor needs additional header data. Use option 7 to add the transaction string. Only certain host processors require the communication header. Triton Systems ©...
  • Page 13 Enter the header data characters provided by the host processor. Press the Enter and Return button. 14. Press the Save and Return button. Press the Back button to navigate to the top menu. Continue to the next section, Modem Testing. Triton Systems ©...

  • Page 14: Modem Testing

    The Left and Right buttons moves the cursor one position per each click. The Backspace button deletes the character to the left of the cursor. 3. Enter a valid phone number. Press the Enter and Return button. Triton Systems ©...
  • Page 15 6. Select Test. Verify the correct phone number provided by the Host processor and re-enter the phone number. Press the Enter and Return button. 7. If the error message, “Connection failed: Unknown”, persists, contact Triton Technical Support. If you have questions regarding this Technical Manual, please contact Technical Support at 1-228-575-3100, option 4 or toll free in the U.S.
