ARGO 15 X3 to X4
Upgrade Instructions
©2024 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline,
Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC. e third
party trademarks that may be identi ed herein are the trademark of their respective owners. Triton disclaims any
affi liation, connection, or association between its products and services, and those of the respective trademark
owners, or any sponsorship or approval of its products and services by such trademark owners.
TDN 07103-08216 Rev A
Advertisement
Related Manuals for Triton ARGO 15
Summary of Contents for Triton ARGO 15
- Page 1 ©2024 Triton Systems of Delaware, LLC. All Rights Reserved. ATMGurus®, the ATMGurus logo and tagline, Triton®, and the Triton logo are all registered trademarks of Triton Systems of Delaware, LLC. e third party trademarks that may be identi ed herein are the trademark of their respective owners. Triton disclaims any affi...
- Page 2 is guide covers converting the Main Board Module and display cable from X3 to X4, for the ARGO-15 ATMs. is manual applies to all service personnel involved in installing, converting, or upgrading hardware on Triton ATMs nationwide and abroad.
- Page 3 X4 Module Board and Display cable for ARGO 15 Green Baseboard ONLY 09200-06511 Tools Required #2 Phillips screwdriver Parts Supplied Description Quantity X4 Module Baseboard Cable|LVDS Display Cable| Non-dimming|15” LCD TDN 07103-08216 Rev A Triton Systems ©...
- Page 4 5. On the Le Image, remove all cables connected to the Baseboard. 6. On the Right Image, locate the two clamps holding the Module, BLUE arrows. Push clamps slightly in the direction of the arrows to release the Module. TDN 07103-08216 Rev A Triton Systems ©...
- Page 5 YELLOW 11. On the Right Image, pull side knob and li print head. Remove the 4-screws, circles. Hold printer assembly as last screw is removed. Save assembly and screws for re-installation. TDN 07103-08216 Rev A Triton Systems ©...
- Page 6 On the Le Image, Remove the ground wires, lower-le of the display bracket, circle. • On the Right Image, Remove the ground wire connected to the printer chute, circle. • Remove the ground wire from display top-le , Right Image, circle. TDN 07103-08216 Rev A Triton Systems ©...
- Page 7 One screw under the cable bundle. • On the Right Image, remove the center-lower display screw, le of the printer location, circle. • Remove the screw right of the printer location, circle. TDN 07103-08216 Rev A Triton Systems ©...
- Page 8 23. Obtain replacement cable from kit (09120-01433). 24. On the Le Image, connect the small and large connectors to the circuit board, arrows. 25. On the Right Image, position cable and reapply the tape over the cable, arrows. TDN 07103-08216 Rev A Triton Systems ©...
- Page 9 29. On the Right Image, set the display glass in the control panel lip, BLUE arrow. Lower display into control panel. Verify the glass side is positioned at the edge, GREEN arrow. 30. Install four screws in the bracket’s top edge, arrows. TDN 07103-08216 Rev A Triton Systems ©...
- Page 10 32. Insert the three screws connecting the ground wires. • On the Le Image, secure ground wire lower-le of the display bracket, circles. • On the Right Image, secure ground wire connecting to the printer chute, circle. TDN 07103-08216 Rev A Triton Systems ©...
- Page 11 36. On the Le Image, position the printer assembly over the four posts and secure with four screws, circles. Verify the ground secured under one of the screws. 37. On the Right Image, connect CN1 and CN8 connectors to the printer circuit board, arrows. YELLOW TDN 07103-08216 Rev A Triton Systems ©...
- Page 12 41. Obtain the X4 (TX6S) Module from the kit. 42. Set Correct Alignment will have equal spacing between the Module and the socket, BLUE arrows. 43. Set Incorrect alignment Module to socket will damage the Module and Baseboard, BLUE arrows. TDN 07103-08216 Rev A Triton Systems ©...
- Page 13 46. An Incorrectly nger placement on the center of the Module will damage the memory components. 47. Visually inspect the Module is seated properly in the socket. e clamps, ovals, hold the Module in the socket. ORANGE arrows shows equal height of gold pins shown. TDN 07103-08216 Rev A Triton Systems ©...
- Page 14 51. If the Module does not easily seat in the socket, remove the module and insert again. 52. Install the Baseboard cover. On the power supply, press the switch to ON (I). e Power-On-Self-Test screen displays Triton CE Application Version 5.0 or higher. 53. Close the print head, if in the open position, GREEN box.
