2 - INSTALLATION INSTRUCTIONS

Heater installation must be carried out by qualified personnel in compliance with local National Codes
(NEC) as well as any other applicable standards. Failure to comply with applicable requirements could
result in personal injury and/or property damage. Wiring procedures and connections shall be made in
accordance with national and local electrical codes having jurisdiction.
MODINE infrared heaters produce radiant heat that warms people and objects, rather than the air around them.
The heater can be wall mounted and includes brackets which allow the user to direct the infrared heat where
desired.
To reduce the risk of fire, do not store or use gasoline or other flammable vapors and liquids in the vicinity of
the heater.
2.1 INSTALLATION CLEARANCE DISTANCES
The minimum clearances indicated on the nameplate and in the user manual must be observed at the time of
CAUTION: High temperatures are present, risk of fire! Keep electrical cords, drapery, furnishings and other
combustibles at least 6 feet (1.8m) from the front of the heater and away from the sides and rear.
DANGER FIRE HAZARD
installation.
Minimum Clearance Distances
Floor Ceiling
6'7" (2 m) 1' (30 cm)
Minimum Clearance Distances
Adjacent walls
18" (45 cm)
5
