INSTALLATION, OPERATION AND MAINTENANCE MANUAL

MODELS

MEQ15A01

During operation, always ensure combustible materials are kept at a safe distance from the heater

body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where

flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in

personal injury/or property damage.

FOR INDOOR AND OUTDOOR COMMERCIAL AND RESIDENTIAL USE

MODINE MANUFACTURING COMPANY * 1500 DE KOVEN AVE * RACINE WI 53403-2552 *

Radiant Infrared Electric Heater

PART

NUMBER

80300

FIRE/EXPLOSION HAZARD WARNING

NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES

VOLTAGE

TOTAL POWER

(V)

120V

CURRENT

(W)

(AMPS)

1500W

12.5V

1-800-828-HEAT (4328)

Table of Contents

Chapters

Need help?

Do you have a question about the MEQ15A01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Modine Manufacturing MEQ15A01

Page 1 Failure to do so can result in personal injury/or property damage. FOR INDOOR AND OUTDOOR COMMERCIAL AND RESIDENTIAL USE 1-800-828-HEAT (4328) MODINE MANUFACTURING COMPANY * 1500 DE KOVEN AVE * RACINE WI 53403-2552 *...
Page 2: Table Of Contents
TABLE OF CONTENTS 1 - SAFETY ................................3 2 - INSTALLATION INSTRUCTIONS .......................... 5 3 - OPERATING INSTRUCTIONS ..........................7 3.2.1 Operation of the Remote Control ...................... 8 4 - MAINTENANCE ..............................9 5 - GROUNDING INSTRUCTIONS ........................... 12 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, AND FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY.
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. 1 - SAFETY WARNINGS WARNING: FIRE OR EXPLOSTION HAZARD...
Page 4 WARNING: PERSONAL INJURY HAZARD - CLEANING AND MAINTENANCE • • To avoid property damage, personal injury Before cleaning the unit or replacing the or death due to electrical shock DO NOT emitter, turn off the main power. Make sure service the unit without turning the unit the heater and/or the emitter is cool before OFF and disconnecting the heater from the handling.
Page 5: Installation Instructions
2 - INSTALLATION INSTRUCTIONS Heater installation must be carried out by qualified personnel in compliance with local National Codes (NEC) as well as any other applicable standards. Failure to comply with applicable requirements could result in personal injury and/or property damage. Wiring procedures and connections shall be made in accordance with national and local electrical codes having jurisdiction.
Page 6: Wall-Mounted Installation
ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box. 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate.
Page 7: Operating Instructions
ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3.
Page 8: Remote Mode
PCB BYPASS MODE When the bypass mode is selected, the heater will operate at 100% of rated power OR may be controlled by other type of external control system. Installer or specifier is responsible for compatibility and safety of controls not included with this heater.
Page 9: Maintenance
Notice: 1. Use 2 pieces AAA, 1.5V batteries (not included) in the remote control. Remove the batteries when not in use for an extended period of time to increase battery life. 2. The heater can be still used normally in the event the remote control is misplaced, however it must be used in PCB bypass mode where the heater will run fully on.
Page 10 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
Page 11 8. Insert the new emitter through the reflector 9. Connect the new emitter to the terminals of openings. Insert the Reflector Shields and bend the heater; screw in the protective plastic caps the tabs back into place. The Reflector Shields hold the emitter in the correct position during operation.
Page 12: Grounding Instructions
5 - GROUNDING INSTRUCTIONS Connection to GFCI protected outlet is recommended for outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 120-volt circuits.
Page 13: Warranty
OTHER REMEDIES PROVIDED BY LAW, ARE LIMITED AS This Warranty (the “Warranty”) shall apply to Products (as DESCRIBED ABOVE. defined below) sold by Modine Manufacturing Company, a Wisconsin corporation (“Seller”) to you (“Buyer”). EXCLUSIONS AND LIMITATIONS: This Warranty is subject to the...
Page 14 2 YEARS 30 MONTHS Condensers, Burners, Sheet Metal As Modine Manufacturing Company has a continuous product improvement program, it reserves the right to change design and specifications without notice. Modine Manufacturing Company 6-1500 DeKoven Avenue Racine, WI 53403 Phone: 1.800.828.4328 (HEAT) www.modinehvac.com...
Page 15 Failure to do so can result in personal injury/or property damage. FOR OUTDOOR RESIDENTIAL AND INDOOR OR OUTDOOR COMMERCIAL USE 1-800-828-HEAT (4328) MODINE MANUFACTURING COMPANY * 1500 DE KOVEN AVE * RACINE WI 53403-2552 *...
Page 16 TABLE OF CONTENTS 1 - SAFETY ................................3 2 - INSTALLATION INSTRUCTIONS .......................... 5 3 - OPERATING INSTRUCTIONS ..........................9 3.2.1 Operation of the Remote Control ....................10 4 - MAINTENANCE ..............................11 5 - grounding instructions............................. 14 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, AND FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY.
Page 17: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. 1 - SAFETY WARNINGS WARNING: FIRE OR EXPLOSTION HAZARD...
Page 18 WARNING: PERSONAL INJURY HAZARD - CLEANING AND MAINTENANCE • • To avoid property damage, personal injury Before cleaning the unit or replacing the or death due to electrical shock DO NOT emitter, turn off the main power. Make sure service the unit without turning the unit the heater and/or the emitter is cool before OFF and disconnecting the heater from the handling.
Page 19: Installation Instructions
2 - INSTALLATION INSTRUCTIONS Heater installation must be carried out by qualified personnel in compliance with local National Codes (NEC) as well as any other applicable standards. Failure to comply with applicable requirements could result in personal injury and/or property damage. Wiring procedures and connections shall be made in accordance with national and local electrical codes having jurisdiction.
Page 20: Electrical Installation
Ceiling Suspended Minimum Clearances ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate...
Page 21: Wall-Mounted Installation
WALL-MOUNTED INSTALLATION HEATER MUST BE INSTALLED WITH BOTH MOUNTING BRACKETS PROVIDED IN THE BOX. 1. Take the heater out of the box and remove all fixing bolts on the brackets at the back of the protective foam inserts. heater. 6. Secure the electrical supply cable so it does not 2.
Page 22: Ceiling Mounted Installation
CEILING MOUNTED INSTALLATION Heater should be hung using rigid mounting brackets, the unit must not be able to swing in any direction under applied load from wind or persons. It is highly recommended that users install the heater with the WARNING ceiling mounting hardware provided.
Page 23: Operating Instructions
ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3.
Page 24: Operation Of The Remote Control
PCB BYPASS MODE When the bypass mode is selected, the heater will operate at 100% of rated power OR may be controlled by other type of external control system. Installer or specifier is responsible for compatibility and safety of controls not included with this heater.
Page 25: Maintenance
Notice: 1. Use 2 pieces AAA, 1.5V batteries (not included) in the remote control. Remove the batteries when not in use for an extended period of time to increase battery life. 2. The heater can be still used normally in the event the remote control is misplaced, however it must be used in PCB bypass mode where the heater will run fully on.
Page 26 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
Page 27 9. Insert the new emitter through the reflector 10. Connect the new emitter to the terminals of openings. Insert the Reflector Shields and bend the heater; screw in the protective plastic caps the tabs back into place. The Reflector Shields hold the emitter in the correct position during operation.
Page 28: Grounding Instructions
5 - GROUNDING INSTRUCTIONS Connection to GFCI protected outlet is recommended for outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 240 Volts.
Page 29: Warranty
OTHER REMEDIES PROVIDED BY LAW, ARE LIMITED AS This Warranty (the “Warranty”) shall apply to Products (as DESCRIBED ABOVE. defined below) sold by Modine Manufacturing Company, a Wisconsin corporation (“Seller”) to you (“Buyer”). EXCLUSIONS AND LIMITATIONS: This Warranty is subject to the...
Page 30 2 YEARS 30 MONTHS Condensers, Burners, Sheet Metal As Modine Manufacturing Company has a continuous product improvement program, it reserves the right to change design and specifications without notice. Modine Manufacturing Company 6-1500 DeKoven Avenue Racine, WI 53403 Phone: 1.800.828.4328 (HEAT) www.modinehvac.com...
Page 31 Failure to do so can result in personal injury/or property damage. FOR OUTDOOR RESIDENTIAL AND INDOOR OR OUTDOOR COMMERCIAL USE MODINE MANUFACTURING COMPANY * 1500 DE KOVEN AVE * RACINE WI 53403-2552 * 1-800-828-HEAT (4328)
Page 32 TABLE OF CONTENTS 1 - SAFETY ................................3 2 - INSTALLATION INSTRUCTIONS .......................... 5 3 - OPERATING INSTRUCTIONS ..........................10 3.1.1 OPERATION OF THE REMOTE CONTROL ...................10 4 - MAINTENANCE ..............................11 5 - GROUNDING INSTRUCTIONS ........................... 14 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY.
Page 33: Safety
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. This heater must be used strictly according to these instructions. SAFETY WARNINGS WARNING: FIRE OR EXPLOSTION HAZARD...
Page 34 WARNING: PERSONAL INJURY HAZARD - CLEANING AND MAINTENANCE • • To avoid property damage, personal injury Before cleaning the unit or replacing the or death due to electrical shock DO NOT emitter, turn off the main power. Make sure service the unit without turning the unit the heater and/or the emitter is cool before OFF and disconnecting the heater from the handling.
Page 35: Installation Instructions
INSTALLATION INSTRUCTIONS Heater installation must be carried out by qualified personnel in compliance with local National Codes (NEC) as well as any other applicable standards. Failure to comply with applicable requirements could result in personal injury and/or property damage. Wiring procedures and connections shall be made in accordance with national and local electrical codes having jurisdiction.
Page 36 Ceiling Suspended Minimum Clearances FIRE HAZARD! HEATER MUST NEVER BE POINTED TOWARDS WALLS OR CEILINGS ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3.
Page 37 WALL-MOUNTED INSTALLATION HEATER MUST BE INSTALLED WITH THE MOUNTING BRACKETS PROVIDED IN THE BOX. 1. Take the heater out of the box and remove all fixing bolts on the brackets at the back of the protective foam inserts and packaging. heater.
Page 38 CEILING MOUNTED INSTALLATION Heater should be hung using rigid mounting brackets, the unit must not be able to swing in any direction under applied load from wind or persons. It is highly recommended that users install the heater with the WARNING ceiling mounting hardware provided.
Page 39 ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3.
Page 40: Operating Instructions
OPERATING INSTRUCTIONS Caution! The heater must be properly installed before it is used. REMOTE CONTROL The remote control must be pointed in the direction of the receiver on the heater body (located on the front face) and must be used within a maximum distance of 6 m. The heater has the option to run at 50% or 100% power.
Page 41: Maintenance
MAINTENANCE WARNINGS 1. Allow the heater and the emitter to cool down before handling. Installation and maintenance must be performed by a qualified technician. Turn oﬀ the power before beginning maintenance. Do not attempt to service or repair the unit while it is running. 5.
Page 42 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
Page 43 9. Insert the new emitter through the reflector 10. Connect the new emitter to the terminals of openings. Insert the Reflector Shields and bend the heater; screw in the white plastic caps the tabs back into place. The Reflector Shields hold the emitter in the correct position during Carefully replace the protective aluminum operation.
Page 44: Grounding Instructions
GROUNDING INSTRUCTIONS Connection to GFCI protected outlet is recommended for outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 240 Volts.
Page 45 OTHER REMEDIES PROVIDED BY LAW, ARE LIMITED AS This Warranty (the “Warranty”) shall apply to Products (as DESCRIBED ABOVE. defined below) sold by Modine Manufacturing Company, a Wisconsin corporation (“Seller”) to you (“Buyer”). EXCLUSIONS AND LIMITATIONS: This Warranty is subject to the...
Page 46 2 YEARS 30 MONTHS Condensers, Burners, Sheet Metal As Modine Manufacturing Company has a continuous product improvement program, it reserves the right to change design and specifications without notice. Modine Manufacturing Company 6-1500 DeKoven Avenue Racine, WI 53403 Phone: 1.800.828.4328 (HEAT) www.modinehvac.com...
