3 DESCRIPTION OF THE DEVICE

General features

The ACR-Smart panel is designed to control all the milking, detachment and washing functions of the unit.
The ACR-Smart can control the milking frequency and the pulsation ratio in a wide range of values to meet
the needs of all systems (both in the high line and low line) and of all types of animals (cattle - sheep -
goats).
The ACR-Smart can perform a stimulation that can be forced, automatic (dependent on the flow of milk) or
manual (activated directly by the milker at any time).
The panel is compatible with swing-over systems in which the unit is detached by moving the arm. In fact,
with the ACR-Smart you can control the pneumatic cylinder responsible for moving the unit from the right-
hand row to the left-hand row and vice versa.
It is suitable for milk transport systems thanks to the alarm indicating the end of the milking process and the
possibility to restart the panel from the last active stage.
The ACR-Smart can be connected to remote start-up devices (AutoStart) and remote stop devices (Quick Lift
Line).

Technical characteristics

General technical characteristics
Dimensions
Weight
Power supply
Power consumption of the panel only
Power consumption of the system
Protection rating (cables installed properly) IP 67
Operating vacuum
Vacuum limit
Operating temperatures (environment)
Transport/storage temperatures
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
130x180x38 mm (5,12x7,08x1,49 in)
0.45 kg (0,99 lb)
24 VDC
100 mA
ACR Smart + CV + LE: 600 mA
between 36 and 50kPa (between 10.63 and 14.76 ''Hg)
60kPa MAX @25°C (17.71 ''Hg MAX @77°F)
+5ºC ÷ +45ºC (+41ºC ÷ +113ºF)
-20ºC ÷ +70ºC (-4ºC ÷ +158ºF)
