Milking

5.3.1 Milking with automatic unit removal

To start the milking process with automatic detachment, press the
or operate the Auto-Start contact.
NOTE
Terminals 5-6 may be used to connect a REMOTE KEY or an AUTO-START device to start the
milking process without having to press the key on the panel
When the automatic milking process starts:
the cylinder releases the unit.
•
after the vacuum/pulsation delay (parameter P.d.), the pulsator is activated and the valve (shut-off)
•
of the flow sensor is opened.
The display then starts counting the milking time. The upper horizontal segment indicates the initial delay
count (parameter I.d.). At the same time, the two vertical segments indicate the opening of the pulsator
channels, flashing alternately.
When the milk presence signal constantly exceeds the value defined by the position of the jumpers, the
panel detects a continuous flow and the horizontal segment of the left-hand display lights up.
When the initial delay has elapsed (parameter I.d.), the upper horizontal segment switches off.
When there is no longer any milk flow, the central segment switches off and the final delay count starts
(parameter F.d.). The detachment operations start when the delay has elapsed.
This manual is the property of InterPuls S.p.A. - any copying, even partial, is strictly prohibited.
The upper line indicates the initial delay count
The central line switched off indicates the
absence of milk
The upper line indicates the initial delay count
The central line indicates the presence of milk
The upper line switched off indicates the end
of the initial delay
The central line indicates the presence of milk
The sole lower line indicates the absence of
milk and therefore the final delay count
In each milking stage, the two vertical lines
flash following the frequency of the pulsator
16
Original instructions
key during the detachment stage
