Multi-Flex Vehicle Mount for Laptops
CONTENTS:
Tray
A
Telescopic Tube
x1
Joint Knobs
Quick
Release
INSTRUCTIONS:
1. Assembling the Base and Mounting to your Vehicle Seat Rail:
E
F
C
B
D
2. Attaching Body to Base:
2
F
2A. Put the stand pole (A) on the base (F) and press the quick release clasp tightly to connect.
To remove the stand, loosen the quick release clasp's screw before pulling the clasp.
AUT-MFVM
INSTRUCTION - MANUAL
B
x1
Washer
D
x1
Screw Nut
1A. Choose the most suitable link
bracket (F) and align in to the screw
(E), base (C), washer (B) and nut (D)
as shown to the left.
A
1
C
x1
Base
E
x1
Screw
1B.
1C.
888-733-4448
x1
F
Set of Mounting Bases
1B. Loosen the bolt (not included) of the
seat rail (Seat and rail not included) .
1C. Install the fully assembled vehicle
mount to the seat rail and screw the bolt
back as shown (Tool not included).
3. Attaching Laptop Tray:
A
3A. Align screw on
top of the support
arm with the hole
at the center of
laptop tray.
3B. Rotate entire
tray clockwise as
illustrated until
securely attached
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CTA AUT-MFVM
Summary of Contents for CTA AUT-MFVM
- Page 1 Multi-Flex Vehicle Mount for Laptops AUT-MFVM INSTRUCTION - MANUAL CONTENTS: Tray Telescopic Tube Washer Base Joint Knobs Quick Release Set of Mounting Bases Screw Screw Nut INSTRUCTIONS: 1. Assembling the Base and Mounting to your Vehicle Seat Rail: 1B. Loosen the bolt (not included) of the seat rail (Seat and rail not included) .
- Page 2 4. Adjusting Laptop Tray Width: 4A. Rotate the knobs located underneath the laptop tray to loosen the connection, and then expand the tray by sliding the knobs outwards. Once its setup in the desired width, rotate the knobs in the opposite direction until securely tightened. 5.
