- Page 1 Cognex DM60S DataMan 60 Reader Limited Availability Used and in Excellent Condition Buy Today! https://www.artisantg.com/98264-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
- Page 2 ® DataMan Reference Manual 04/18/2017 Version: 5.7.0.102 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 3: Legal Notices
Copyright © 2017. Cognex Corporation. All Rights Reserved. Portions of the hardware and software provided by Cognex may be covered by one or more U.S. and foreign patents, as well as pending U.S. and foreign patents listed on the Cognex web site at: http://www.cognex.com/patents. -
Page 4: Table Of Contents
Table of Contents Table of Contents Legal Notices Table of Contents Symbols Getting Started About DataMan 60 DataMan 60 Accessories Cables Power Supply Mounting Brackets Control Box DataMan 60 Systems Model Limitations Reader Layout Dimensions Setting Up Your DataMan 60 Setting the Focus Position Field of View and Reading Distances DataMan 60 Imager Specifications... - Page 5 Table of Contents Precautions Reader Programming Codes Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 6: Symbols
Symbols Symbols The following symbols indicate safety precautions and supplemental information. WARNING: This symbol indicates the presence of a hazard that could result in death, serious personal injury or electrical shock. CAUTION: This symbol indicates the presence of a hazard that could result in property damage. Note: Notes provide supplemental information about a subject. -
Page 7: Getting Started
The DataMan Fixed Mount Readers Reference is a complete online hardware reference for the DataMan fixed- mount ID readers. Cognex->DataMan Software v x.x.x->Documentation->English->DM60 ->Fixed Mount Reference Manual The DataMan Questions and Answers document provides context-sensitive information. You can view this help inside the DataMan Setup Tool or as a stand-alone help file. -
Page 8: Dataman 60 Accessories
Getting Started DataMan 60 Accessories Cables USB Cable, 1.5 m (DM100-USB-000) USB Cable, 3 m (DM100-USB-030) USB and Flying Leads I/O Cable, 2.0 m (DM-USBIO-00) RS-232 and Flying Leads I/O Cable, 2.5 m (DM-RS232IO-00) RS-232 Cable, 1.5 m (DM100-RS232-000) Extension Cable, 5 m (DM100-EXTCBL-000) Flying Leads Connection Cable, 5 m (DM50-PWRIO-05) Ethernet Cable: use any standard CAT5/5e, SF/FTP or S/FTP cable RS-232/USB adapter connector (DM100-PATCH-000) -
Page 9: Control Box
Getting Started Universal Mounting Bracket (DM50-UBRK-000) Control Box Control Box (DM-CTRLBOX-00) Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 10: Dataman 60 Systems
Getting Started DataMan 60 Systems Omni-directional 1-D IDQuick™ — Well 1DMax+™ with Code Reading marked 2-D Code HOTBARS™ Reading DataMan 60L (DMR-60L-00) √ DataMan 60QL (DMR-60QL-00) √ √ DataMan 60S (DMR-60S-00) √ √ √ Model Limitations S models do not have Burst and Continuous trigger modes. 60QL 1-D and Stacked Codes Yes, oriented... -
Page 11: Reader Layout
Getting Started Reader Layout The following image shows the characteristics of the DataMan 60reader. Internal illumination 3-position lens cap Focal position indicator External illumination connector Status LEDs: - Power: YELLOW = Power ON - Communication: Flashing YELLOW - Good / bad read: GREEN = good read / RED = bad read - Error: RED = error, check device log LED aimer Lens... -
Page 12: Dimensions
Getting Started Dimensions Observe the following DataMan 60 reader dimensions when installing your reader. The attachment points have the following characteristics: M3 thread Maximum thread depth: 6 mm 1.3 N-m (11.5 in-lb) maximum torque CAUTION: Use both attachment points when mounting your device. Artisan Technology Group - Quality Instrumentation ... - Page 13 Getting Started Tip: Some applications can benefit from mounting the system at a slight angle (15 degress) to reduce reflection from the inspected surface back to the reader. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 14: Setting Up Your Dataman 60
Setting Up Your DataMan 60 Setting Up Your DataMan 60 Setting the Focus Position DataMan 60 can operate in one of three distance ranges. To set the focus position: 1. Remove the lens cover. 2. Set the focus position to 45, 70, or 110: turn the lens cap clockwise (45->70->110) to focus to a larger distance; turn the lens cap counter-clockwise (110->70->45) to focus to a shorter distance. -
Page 15: Field Of View And Reading Distances
Setting Up Your DataMan 60 Field of View and Reading Distances The following charts show the field of view (FoV) of the DataMan 60 series readers. Reading distance values are also provided for 1-D and 2-D example code distances. This chart shows the supported range of reading distances at 45 mm focus position. This chart shows the supported range of reading distances at 70 mm focus position. -
Page 16: Dataman 60 Imager Specifications
Setting Up Your DataMan 60 DataMan 60 Imager Specifications Specification DataMan 60 Series Imager Image Sensor 1/3 inch CMOS Image Sensor Properties 4.51 mm x 2.88 mm (H x V), 6.0 µm square pixels Image Resolution (pixels) 752 x 480 Electronic Shutter Speed 18 µs to 25 ms exposure Image Acquisition... -
Page 17: Using Your Dataman 60
3. Connect the DataMan 60 reader to your PC. 4. Choose Start > Programs > Cognex > DataMan Software v x.x.x > Setup Tool to launch the DataMan Setup Tool. The detected readers will appear under the COM ports. -
Page 18: External Triggers
Using Your DataMan 60 External Triggers If you are using external triggering, you can use any of these methods to trigger your DataMan 60 series reader: Send a pulse on the I/O cable: Input 0 (white) Input 1 (white/black) Send a serial trigger command over the RS-232 connection or the Ethernet connection. Press <CTRL>-T on the keyboard while the DataMan Setup Tool has the input focus. -
Page 19: Connections, Optics And Lighting
Connections, Optics and Lighting Connections, Optics and Lighting I/O Cable The I/O cable provides access to trigger and high-speed outputs. Unused wires can be clipped short or tied back using a tie made of non-conductive material. For RS-232, use the Power Supply return path for ground. Note: GND (Pin 4) is connected to the reader housing, cable shield, and DB15 shell. -
Page 20: Usb And Flying Leads I/O Cable
Connections, Optics and Lighting USB and Flying Leads I/O Cable You can connect a cable with USB and flying leads (DM-USBIO-00) to the cable that is attached to the device. The following table shows the pinout and color description of the flying leads. This is a female connector/socket. - Page 21 Connections, Optics and Lighting This is a female connector/socket. Color Signal White Input-0 White/Black Input-1 Light Blue/Black Output-1 Light Blue/Yellow Output-Common Light Blue/Green Output-Strobe Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 22: Flying Leads Cable
Connections, Optics and Lighting Flying Leads Cable You can connect a cable with flying leads (DM50-PWRIO-05) to the cable that is attached to the device. The following table shows the pinout and color description of the flying leads. This is a female connector/socket. Color Signal Green... -
Page 23: Digital Input Lines
Connections, Optics and Lighting Digital Input Lines Inputs are not galvanic isolated but need to be referenced to ground. External Wiring Examples: Digital Input Lines Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 24: Digital Output Lines
Connections, Optics and Lighting Digital Output Lines The digital outputs can be used as either NPN (pull-down) or PNP (pull-up) lines. For NPN lines, the external load should be connected between the output and the positive supply voltage (<24 V). The outputs pull down to less than 3 V when ON, which causes current to flow through the load. -
Page 25: External Wiring Examples: Digital Output Lines
Connections, Optics and Lighting External Wiring Examples: Digital Output Lines NPN: PNP: Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 26: Illumination Strobe Output
Connections, Optics and Lighting Illumination Strobe Output The strobe output is provided by a diode that is added to the push-pull circuit, with series to the pull-up transistor. This diode blocks the higher voltage when the output is pulled up when used as open-collector type driving, but enables the driving of high level in TTL mode. -
Page 27: External Load Strobe Output
Connections, Optics and Lighting External Load Strobe Output NPN: PNP: Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 28: Multi-Port Connections
When a reader transmits data, it is passed through each of the readers in the chain between it and the PC. Because of the large number of possible configurations, Cognex does not supply cabling for multi-port DataMan 60 connections. Instead, you must construct your own cable that meets the requirements of your system configuration. -
Page 29: Multi-Port Usage Notes
Connections, Optics and Lighting Multi-Port Usage Notes You can obtain the best results when using multi-port connections by keeping the following usage guidelines in mind as you design your system: The maximum cable length between any two DataMan readers or between the PC and any DataMan reader should be no greater than 15 meters. -
Page 30: Cleaning/Maintenance
Cleaning/Maintenance Cleaning/Maintenance Cleaning the Reader Housing To clean the outside of the reader housing, use a small amount of mild detergent cleaner or isopropyl alcohol on a cleaning cloth. Do not pour the cleaner directly onto the reader housing. CAUTION: Do not attempt to clean any DataMan product with harsh or corrosive solvents, including lye, methyl ethyl ketone (MEK) or gasoline. -
Page 31: Compliance Information, Warnings And Notices
FCC Part 15, Subpart B, Class A EN55022, Class A European Community EN55024 EN60950 Note: For the most up-to-date CE declaration and regulatory conformity information, please refer to the Cognex online support site: http://www.cognex.com/Support. Safety and Regulatory European WARNING: This is a class A product. In a domestic environment this product may cause radio Compliance interference in which case the user may be required to take adequate measures. - Page 32 Compliance Information, Warnings and Notices In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a sound way.
- Page 33 Precautions Precautions Observe these precautions when installing the Cognex product, to reduce the risk of injury or equipment damage: To reduce the risk of damage or malfunction due to over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply, route all cables and wires away from high-voltage power sources.
-
Page 34: Reader Programming Codes
Reader Programming Codes Reader Programming Codes Reset Scanner to Factory Defaults Reboot Scanner Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 35 Copyright © 2017 Cognex Corporation. All Rights Reserved. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
