DataMan
60
Quick Reference Guide
2019 October 08
Revision: 6.1.6SR1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataMan 60 and is the answer not in the manual?

Questions and answers

Related Manuals for Cognex DataMan 60

Summary of Contents for Cognex DataMan 60

  • Page 1 ® DataMan Quick Reference Guide 2019 October 08 Revision: 6.1.6SR1.5...
  • Page 2 Precautions To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: Route cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply.

  • Page 3: Product Overview

    Product Overview Internal illumination 3-position lens cap Focal position indicator External illumination connector Status LEDs LED aimer Lens Directly connected cable terminating in a DB15 connector providing: power, I/O, USB, and RS-232 connectivity Ethernet RJ-45 connector Mounting points...

  • Page 4: Dataman 60 Accessories

    DataMan 60 Accessories CABLES USB Cable, 1.5 m (DM100-USB-000), USB Cable, 3 m (DM100-USB-030) USB and Flying Leads I/O Cable, 2.0 m (DM-USBIO-00) RS-232 and Flying Leads I/O Cable, 2.5 m (DM-RS232IO-00) RS-232 Cable, 1.5 m (DM100-RS232-000), Extension Cable, 5 m (DM100-EXTCBL-000)
  • Page 5 Dimensions...

  • Page 6: Field Of View And Reading Distances

    Field of View and Reading Distances Focus position Distances in mm/2D min. code Distances in mm/1D min. code 6 MIL 45 mm 33-51 34-51 4 MIL 31-57 8 MIL 30-56 6 MIL 27-60 10 MIL 37-66 10 MIL 25-61 12 MIL 70 mm 44-74 6 MIL...

  • Page 7: Connecting The Reader

    2. Connect the reader to the PC. 3. Connect the reader to an Ethernet network with a standard CAT5/5e, SF/FTP or S/FTP cable. For information on the pinout and the wire colors, see section Connections, Optics and Lighting in the DataMan 60 Reference Manual.

  • Page 8: Installation

    Cognex > DataMan Software vx.x.x > Documentation. Note: Cables are sold separately. If a standard component is missing or damaged, immediately contact your Cognex Authorized Service Provider (ASP) or Cognex Technical Support. CAUTION: All cable connectors are keyed to fit the connectors on the reader.

  • Page 9: Connect The Ethernet Cable

    Connect the Ethernet Cable 1. Connect the Ethernet cable's RJ-45 connector to a switch/router or PC, as applicable. Connect the Breakout Cable Note: You can clip unused wires short or use a tie made of non-conductive material to tie them back. For RS-232, use the Power Supply return path for ground.

  • Page 10: Install Software And Documentation And Connect The Reader

    1. Connect the RS-232 cable to your reader. 2. Connect the cable to a power supply. To configure a DataMan 60 reader, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site: http://www.cognex.com/support/dataman.

  • Page 11: Dataman 60 Specifications

    DataMan 60 Specifications 98 g (including cable) Weight Operating 0 ºC — 40 ºC (32 ºF — 104 ºF) Temperature Storage Temperature -10 ºC — 60 ºC (-14 ºF — 140 ºF) Maximum Humidity 95% (non-condensing) IP40 Environmental Vibration IEC 60068-2-6 and 60068-2-27 LED Safety IEC 62471: Exempt risk group, no further labeling is required.

  • Page 12: Dataman 60 Imager Specifications

    DataMan 60 Imager Specifications Specification DataMan 60 Series Imager Image Sensor 1/3 inch CMOS Image Sensor Properties 4.51 mm x 2.88 mm (H x V), 6.0 µm square pixels Image Resolution (pixels) 752 x 480 Electronic Shutter Speed 18 µs to 25 ms exposure...

  • Page 13: Compliance Statements

    2014/30/EU Electromagnetic Compatibility. For further information please contact: Cognex Corporation, One Vision Drive Natick, MA 01760 USA. Cognex Corporation shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked.

  • Page 14: Led Safety Statement

    Exempt Risk Group. No further labeling is required. For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE).
  • Page 15 You may also contact your supplier for more information on the environmental performance of this product.

  • Page 16: China Rohs

    China RoHS Hazardous Substances 有 害 物 质 Part Name Lead (Pb) Mercury Cadmium Hexavalent Polybrominated Polybrominated 部 件 名 称 铅 (Hg) (Cd) Chromium biphenyls (PBB) diphenyl ethers 汞 镉 多 溴 联 苯 (Cr (VI)) (PBDE) 六 价 铬 多...
  • Page 17 Copyright © 2019 Cognex Corporation. All Rights Reserved.
