WIRING
TO CONNECT OPTIONAL HEATER ENABLE CABLE SEE
STEP 1 TO 4
The local isolator must be connected to the mains as part of the fixed
wiring. Connect the N, L and E cores of the power cable to the matching
terminals on the local isolator.
8
7
6
1
F
E
D
C
B
A
Remove base cap (two screws)
8
7
6
3
BLUE WIRES
Heater enable
Volt free
connection
Wire in 2 core cable
5
PIV & MIV Air Source
VENTILATION UNIT
5
4
3
2
1
5
4
3
2
1
RED WIRES
SHOULD YOU ENCOUNTER ANY PROBLEMS
INSTALLING THIS UNIT, CALL US ON:
LOCAL ISOLATOR
N E L
POWER CABLE
2
F
E
D
C
B
Make small hole in grommet
A
and thread 2 core cable through
8
7
6
4
F
E
D
C
B
A
Replace base cap (two screws)
8
7
6
MAINS SUPPLY
230V 50/60HZ
N
E
L
5
4
3
2
1
5
4
3
2
1
01423 810 810
F
E
D
C
B
A
