66077-001 Rev 01
GED1455
Z-Wave® Plus
Installation and User Guide
Required tools
Ruler
Phillips head screwdriver
Additional Tools (depending on application)
Hammer
Wood block
1
Prepare the door and check dimensions
If drilling a new door, use the supplied template and the complete
door drilling instructions available at www.weiserlock.com/doorprep.
A
Measure to confirm that the hole in
the door is 54 mm (2 1/8 in).
See
note
below*
54 mm
2 1/8 in
*If you are installing this lever below
an existing lock or you plan to install a
lock above this lever, make sure that the
distance between holes is at least 165 mm
(6 1/2 in).
2
Install the latch and strike
A
Hold the latch in front of the door hole, with the latch
face flush against the door edge.
A
B
Is the semi-circular hole of the latch centred in
the door hole?
YES
or
No adjustment is required.
Proceed to next step.
Weiser
Technical Support
1-800-501-9471
www.weiserlock.com
B
Measure to confirm that the backset is
either 60 or 70 mm (2 3/8 or 2 3/4 in).
b a
60 or 70 mm
2 3/8 or 2 3/4 in
C
Adjust the latch face (if needed).
flush
NO
Move the pin to
extend the latch.
A
Parts in the box
Latch
A
A2 A3
Strike
C
Keys
Spindle
E
F2
Levers
Y1
C
Measure to confirm that the hole in
the door edge is 25 mm (1 in).
c k
s e
t
For square corners
Proceed to step 2D.
For round corners
1. Remove square corner faceplate.
A
2. Install round corner faceplate.
Ensure A2
snaps into
A2
place.
For doors without chiselled edge
1. Remove plates.
A
2. Install drive-in collar.
A3
1 / 4
Exterior
Interior
Assembly
Assembly
F
Mounting
Fasteners
Plate
G
26298
SmartKey
Tool
H
22044
Batteries
27526
J
Y2
D
Measure to confirm that the door is
between 35 and 44 mm (1 3/8 and
1 3/4 in) thick.
25 mm
1 in
actual
size
N
D
Is the door edge chiselled?
YES
or
chiselled
slant of latch
bolt faces
door frame
N (2x)
E
Install strike on the door frame.
P (2x)
M
L
K
N
P
Z
T
64156
U
V
35 – 44 mm
1 3/8 – 1 3/4 in
P
NO
not
chiselled
slant of latch
bolt faces
door frame
wood block
C
door frame
