Add the lock to your smart home system
A
Initiate the process to add
the lock to your system at
your smart home controller.
Refer to your smart home
system instructions for
more information.
8
Add user codes (30 max)
It is recommended that you add and
delete all user codes through your smart
home control system. If your system
does not allow this, codes may be added
directly to the lock as shown here.
Programming Timeout
If no button is pressed for 5 seconds, the
system will time out and you will need to
restart the procedure.
9
Test the lock (review normal operation)
Confirm that the code(s) added in previous step can unlock the door.
Locking the Door
Press Lock button once.
10
Re-key the lock (if needed) and install the battery cover
A
Re-key the lock (if needed).
a
K
IMPORTANT:
Remove battery
pack before
re-keying.
B
When prompted by your smart home system to add the
lock, press button "A" on the lock interior one time. The
red LED will illuminate when the lock enters Add Mode.
button "A"
Please allow time for the controller to add the lock.
A
Make sure the door is open. Press
the Program button the number of
times that corresponds to the user
code position being programmed.
Example: If
programming
the third code,
press the button
three times.
D
What lights and sounds does the lock produce?
One green flash with one beep*
1x
green
Programming was successful.
*Beeping sound will only be heard if switch #3 (on the lock interior) is in the on positon. See "Switches and Status LED Colours" on page 4.
Mastercode
For enhanced security, a mastercode may be used when adding and deleting user codes. For more information about the mastercode, download the Programming
and Troubleshooting Guide on the SmartCode 5 Lever page at www.weiserlock.com.
Re-key the lock to work with your
b
existing key. See the supplied
SmartKey Re-key Instructions
for more information.
H
C
D
B
Enter user code. A total of 30 user
codes may be programmed.
Each user code must
between 4 and 8 digits,
depending on your
smart home system.
Three red flashes with three beeps*
or
red
Programming was unsuccessful.
Make sure the user code is not a duplicate and that it is
between 4 and 8 digits during your next attempt.
Unlocking the Door
Enter user code.
Tip: You can press the
Lock button before
entering your user
code to light up the
keypad at night.
B
Install the battery cover.
c a
K
Reinstall
battery
pack.
3 / 4
If successful, re-name the lock in your system
(if applicable).
If unsuccessful, follow your system's instructions to
remove the lock from the controller and any other
network, then press button "A" on the lock one time.
Perform steps 7A-7C again.
If still unsuccessful, consult the Programming and
Troubleshooting Guide on the SmartCode 5 Lever
page at www.weiserlock.com.
C
Press Lock button once.
be a unique code
or
3x
Programming time out.
Make sure not to pause for more than 5
seconds during programming.
b
M
Two beeps*
2x
actual
size
V
V (2x)
