ProMinent DULCOMETER diaLog X Installation And Configuration Manual page 10

Navigation in the controller's menu display
'Calibrate' menu
'Setup' menu
10
All systems
Cooling tower pH
PID ORP
PID ORP
Chlorine
Cooling tower ORP
Cooling tower conductivity
Water meter
Turbine meter
Today
0 errors 0 warnings
Fig. 5: All applications in one view
Menu
System selection
Alert list
Calibrate
Setup
Logbooks
Update
Diagnostics
Fig. 6: 'System selection' menu
1. Press "MENU" to start.
'System selection' menu to manage which applications are
2. Use the
to be displayed.
'Alert list' displays current and unconfirmed alarms.
The
'calibrate' menu includes calibration instructions as a step-by-step
The
Ä Chapter 16 'Calibrating the controller' on page 107 .
guide,
Setup
Device
Applications
Hardware
Modbus
User Passwords
Fig. 7: 'Setup' menu
'Setup' menu to:
You can use the
Adapt device settings
n
Select / configure applications
n
Check hardware settings
n
Configure Modbus communication
n
Set user passwords
n
11:54:11
6.8 pH
100%
100.0
72.01 ppm
0.5 mV
744µS
11 m3
12.2 l/h
11.0 l
A3559
10.10.6.106
empty
A3560
C0119
