Touchboards 481A50 Setup Instructions

POS 0 POS 1
Position
Displacement mm
Displacement Inch
Total height mm
Total height Inch
VESA top mm
VESA top Inch
VESA center mm
VESA Center Inch
Center panels can be set at 6 different heights
Positions 0 (standard) to 5.
You may want to set the height according to the
situation of use.
• The top position of the VESA pattern moves
up with the center panels, the center position
depends on the size of the VESA pattern, an
example is shown for VESA 600x600 mm.
• The Touchpanel can always be moved down
®
on the BalanceBox
height specified for the Mobile stand, this is
important for moving through doorways.
POS 2
0 1
0 70
0" 2.8"
1955 1980
75.8" 78"
1657 1727
65.2" 68"
1357 1427
53.4" 56.2"
below the maximum
Height set up Instructions
POS 3 POS 4
2 3
140 210
5.5" 8.3"
2050 2120
80.7" 83.5"
1797 1867
70.7" 73.5"
1497 1567
58.9" 61.7"
Example:
600x600
VESA
pattern
order number: 481A50
Mobile Stand
®
for the BalanceBox 650
POS 5
4 5
280 350
11.0" 13.8"
2190 2260
86.2" 89"
1937 2007
76.3" 79"
1637 1707
64.4" 67.2"
