Summary of Contents for Gefen DVIAUD-2-HDMI
- Page 1 DVI Audio to HDMI Adapter U S E R M A N U A L www.gefen.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. DVI Audio to HDMI Adapter is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Features Panel Descriptions Pin Confi guration Connecting and Operating the DVI Audio to HDMI Specifi cations Warranty... -
Page 4: Introduction
Our Commitment Gefen will always offer the fi nest quality product at the best possible price. Included in that price is a lifetime of support from a team of outstanding engineers. Introduction The DVI Audio to HDMI™... -
Page 5: Features
FEATURES Features • Allows you to connect computers or other sources with DVI output and SPDIF to an HDMI™ display • Encodes digital audio onto the video signal for HDMI™ video and audio • Supports HDTV resolutions • Supports resolutions up to 1080p, 2K, and 1920 x 1200 •... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS FRONT PANEL SPDIF Input DVI Input BACK PANEL Connects to HDMI Output 5VDC power supply... -
Page 7: Pin Confi Guration
PIN CONFIGURATION DVI-I Input Pin Assignment DVI-Digital(DVI-D): Supports digital-only connections between the host computer and display. This interface is designed for a 12 or 24-pin connections to enable single or dual-link mod activation. Signal Assignment Signal Assignment Signal Assignment T.M.D.S. Data2- T.M.D.S. -
Page 8: Connecting And Operating The Dvi Audio To Hdmi
CONNECTING AND OPERATING THE DVI AUDIO TO HDMI How to Connect the DVI Audio to HDMI 1- Connect your HDMI compliant display to the HDMI female connector at the output side of the DVI Audio to HDMI Adapter. 2- Then simply connect the supplied DVI cable, from your source, to the input side of the DVI Audio to HDMI Adapter. -
Page 9: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ................1.65 Gbps Pixel clock frequency ................24Mhz - 165 Mhz Input Video Signal ..................1.2 volts p-p Input DDC Signal ..................5 volts p-p (TTL) HDMI Connector ................Type A (19 pin) Female DVI Connector ............. DVI-I (29 pin) female (digital only) Audio Connector ..................... -
Page 10: Warranty
If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
