Summary of Contents for Gefen DVI-EDIDP
- Page 1 DVI Detective Plus U S E R M A N U A L www.gefen.com...
- Page 2 20600 Nordhoff St. Chatsworth, CA 91311 support@gefen.com www.gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying The DVI Detective Plus is a trademark of Gefen Inc. ASKING FOR ASSISTANCE (818) 772-9100 (800) 545-6900...
-
Page 3: Table Of Contents
Introduction Features Panel Layout Connecting and Operating the DVI Detective Plus Connecting and Operating the DVI Detective Plus Using a Pre-Programmed EDID Using a Pre-Programmed EDID Pre-Programmed EDID Diagram Write Protecting the DVI Detective Plus Specifi cations Warranty TABLE OF CONTENTS... -
Page 4: Introduction
Next, you put it into place on the video output of your video source and restart your equipment. When all sources and displays are powered on, seamless functioning of video source and display equipment will commence. -
Page 5: Features
Can eliminate CAT-5 lines used to carry DDC signals when extending computer video • Passes HDCP copy-protection protocols for full HDTV, using an HDMI to DVI adapter (not included) • No power required after initial programming Includes: (1) DVI Detective Plus (1) 1’... -
Page 6: Panel Layout
PANEL LAYOUT Front Panel Power LED Programming Indicator Button Back Panel EDID & HDCP Write Switches Protection Switch... -
Page 7: Connecting And Operating The Dvi Detective Plus
CONNECTING AND OPERATING THE DVI DETECTIVE PLUS Before proceeding, please ensure that the write protect switch is in the E (write enabled) position and all SETTING DIP SWITCHES are in the OFF (down) position Please see the diagram on the page 8. Connect the display to the DVI Out port on the DVI Detective Plus. -
Page 8: Connecting And Operating The Dvi Detective Plus
CONNECTING AND OPERATING THE DVI DETECTIVE PLUS Once a successful EDID record is complete, remove the 5V DC power supply from the DVI Detective Plus. At this time, it is recommended that you write protect the DVI Detective Plus to prevent an accidental overwrite. Please see page 9 for instructions on this procedure. -
Page 9: Using A Pre-Programmed Edid
USING A PRE-PROGRAMMED EDID The DVI Detective Plus includes 5 built-in manually-selectable generic EDIDs (display identities) for forcing several standard home theater setups with multi- channel audio and standard HDTV resolutions. This functionality is vital when equipment reaches a state of indeterminate function and will not respond to signals or controls properly, and a certain resolution size with specifi... -
Page 10: Using A Pre-Programmed Edid
USING A PRE-PROGRAMMED EDID EDID Resolutions - Aspect Ratio 720 x 480p 16:9 1440 x 480p 16:9 1280 x 720p 16:9 1920 x 1080p 16:9 1920 x 1080i 16:9 (native) 720 x 480p 16:9 1440 x 480p 16:9 1280 x 720p 16:9 1920 x 1080i 16:9 1920 x 1080p 16:9 (native) Choose the desired EDID from the table above and enable the corresponding... -
Page 11: Pre-Programmed Edid Diagram
PRE-PROGRAMMED EDID DIAGRAM Pre-Programmed EDID DIP SWITCHES... -
Page 12: Write Protecting The Dvi Detective Plus
WRITE PROTECTING THE DVI DETECTIVE Write protection switch Once the DVI Detective is programmed and working, you can write protect the unit to prevent an accidental overwrite. This is done by simply moving the write protect switch to the D (write disabled) position. By default, the unit is shipped in the E (write enabled) position. -
Page 13: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 165 MHz Input Video Signal ... 1.2 volts p-p Input DDC Signal ... 5 volts p-p (TTL) Maximum Single Link Range ... 1920 x 1200 x 60hz DVI Input/Output Connector Type ... DVI-I Power Consumption ... 5 Watts (max.) Power Supply ...
