LUNA2000-100KTL-M1 Smart Power Control System
User Manual
Issue
01
Date
2022-11-10
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUNA2000-100KTL-M1 and is the answer not in the manual?

Questions and answers

Related Manuals for Huawei LUNA2000-100KTL-M1

Summary of Contents for Huawei LUNA2000-100KTL-M1

  • Page 1 LUNA2000-100KTL-M1 Smart Power Control System User Manual Issue Date 2022-11-10 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: About This Document

    Purpose This document describes the installation, electrical connections, commissioning, maintenance, and troubleshooting of the LUNA2000-100KTL-M1 Smart Power Control System (also referred to as Smart PCS). Before installing and operating the Smart PCS, ensure that you are familiar with the features, functions, and safety precautions provided in this document.

  • Page 4: Change History

    LUNA2000-100KTL-M1 Smart Power Control System User Manual About This Document Change History Changes between document issues are cumulative. The latest document issue contains all updates made in previous issues. Issue 01 (2022-11-10) This issue is used for first office application (FOA).

  • Page 5: Table Of Contents

    LUNA2000-100KTL-M1 Smart Power Control System User Manual Contents Contents About This Document ........................ii 1 Safety Information ........................1 1.1 General Safety ................................1 1.2 Personnel Requirements ............................... 2 1.3 Electrical Safety ................................3 1.4 Installation Environment Requirements ........................4 1.5 Mechanical Safety ................................
  • Page 6 LUNA2000-100KTL-M1 Smart Power Control System User Manual Contents 5.6 Connecting DC Power Cables ............................ 33 5.7 Connecting AC Power Cables ............................. 34 5.8 Connecting FE Communications Cables ........................36 5.9 Closing Maintenance Compartment Doors ......................... 40 5.9.1 Closing the DC Maintenance Compartment Door ....................40 5.9.2 Closing the AC Maintenance Compartment Door ....................

  • Page 7: Safety Information

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 1 Safety Information Safety Information 1.1 General Safety Statement Before installing, operating, and maintaining the equipment, carefully read this document and observe all safety instructions provided herein and written on the equipment itself.

  • Page 8: Personnel Requirements

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 1 Safety Information Ensure that power is off during installation. ⚫ Do not install, use, or operate outdoor equipment and cables (including but not limited to moving equipment, operating equipment and cables, inserting connectors to or removing...

  • Page 9: Electrical Safety

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 1 Safety Information ⚫ Only professionals or authorized personnel should replace equipment or components (including software). ⚫ Professionals: personnel who are trained or experienced in equipment operations and fully understand the potential hazards involved in equipment installation, operation, and maintenance ⚫...

  • Page 10: Installation Environment Requirements

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 1 Safety Information ⚫ Before making electrical connections, switch off the corresponding disconnectors on the AC and DC sides to cut the power supply if people may contact energized components. ⚫ Before connecting a power cable, check that the label on the power cable is correct.

  • Page 11: Using Ladders

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 1 Safety Information Using Ladders ⚫ Use wooden or fiberglass ladders when you need to perform live working at heights. ⚫ When a step ladder is used, ensure that the pull ropes are secured and the ladder is held firm.

  • Page 12: Drilling Holes

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 1 Safety Information − Do not climb higher than the fourth rung of the ladder from the top. Ensure that your body's center of gravity does not shift outside the legs of the −...

  • Page 13: Product Overview

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Product Overview 2.1 Model Model Number Figure 2-1 Model Table 2-1 Model number description Meaning Description Product family LUNA2000: Smart PCS name Power level 100K: The power level is 100 kW.

  • Page 14: Functions And Features

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Figure 2-2 Position of the model label on the external package (1) Position of the model label 2.2 Functions and Features Functions ⚫ The Smart PCS implements rectification and inversion through a three-phase three-level converter.

  • Page 15: Appearance

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Figure 2-3 Power grid type 2.3 Appearance Appearance Figure 2-4 Appearance (1) AC maintenance (2) Communications cable (3) Panel compartment hole (FE) (4) Protective cover (5) DC maintenance (6) LED indicator...
  • Page 16 LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview (10) Communications cable (11) AC power cable hole (12) Ventilation valve hole (COM) (13) USB portUSB port (14) DC power cable hole (USB) Note [1]: The security Torx wrench is delivered with the device and is tied to the bracket on the top of the chassis.

  • Page 17: Working Principle

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Label Name Description ⚫ Delayed discharge There may be a risk of shock when the device is powered on. Only qualified and trained electrical technicians should install and operate the device.

  • Page 18: Working Modes

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Figure 2-6 Circuit diagram 2.4.2 Working Modes The Smart PCS can work in standby, operating, or shutdown mode. Figure 2-7 Working modes Table 2-3 Working mode description Working Description Mode...

  • Page 19: Typical Application Scenario

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Working Description Mode commands. ⚫ The Smart PCS enters Shutdown mode after detecting a fault or receiving a shutdown command. Shutdown ⚫ In Standby or Operating mode, the Smart PCS enters Shutdown mode after detecting a fault or receiving a shutdown command.
  • Page 20 LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Item Recommended Quantity Source Model/Specifications System Company (ESS for short) Smart PCS LUNA2000-100KTL-M1 Purchased from the Company Smart Rack Purchased Controller (rack from the controller) Company Smart Array SmartACU2000D-D-00 Purchased...
  • Page 21 LUNA2000-100KTL-M1 Smart Power Control System User Manual 2 Product Overview Figure 2-9 Communication networking diagram (FE) Figure 2-10 Communication networking diagram (fiber ring network) Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 22: Storage

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 3 Storage Storage ⚫ Do not transport devices without appropriate packaging. ⚫ Do not tilt the packaging or place it upside down. If the Smart PCS is not installed immediately, it should be stored according to the requirements outlined in this section.

  • Page 23: Installation

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation Installation 4.1 Environment Requirements Basic Requirements ⚫ Do not install the Smart PCS in working or living areas. ⚫ If the device is installed in public places (such as parking lots, stations, and factories) other than working and living areas, install a protective net outside the device and erect a warning sign to isolate it.
  • Page 24 LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation ⚫ Class D environment: Sea environments or outdoor areas within 500 m away from the sea. If a site is near a pollution source, it is within 1500 m away from heavy pollution sources such as smelteries,...

  • Page 25: Preparing Tools

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation Installation Angle Requirements Figure 4-2 Installation angle 4.2 Preparing Tools Before installation, the following tools need to be prepared. Installation Tools Drill bit (Ф14 mm Hammer drill Insulated torque socket Phillips insulated and Ф16 mm)
  • Page 26 LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation Wire strippers Rubber mallet Utility knife Diagonal pliers RJ45 crimping Hydraulic pliers Cable cutter Vacuum cleaner tool Steel measuring Level Cable tie Marker tape Heat-shrink tubing Heat gun Step ladder Digital multimeter...

  • Page 27: Pre-Installation Checks

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation Personal Protective Equipment (PPE) Safety shoes Goggles Dust mask Insulated gloves Safety helmet Reflective vest Protective gloves 4.3 Pre-installation Checks Checking the Outer Packing Before unpacking the device, check the outer packing for damage, such as holes and cracks, and check the device model.

  • Page 28: Moving The Smart Pcs

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation 4.4 Moving the Smart PCS If the installation position is too high to install the Smart PCS directly on the mounting bracket, run a rope (strong enough to bear the weight of the Smart PCS) through the two lifting eyes, and use it to hoist the Smart PCS.

  • Page 29: Installing The Smart Pcs

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation Figure 4-3 Manual handling Figure 4-4 Hoisting ----End 4.5 Installing the Smart PCS Prerequisites The mounting brackets (including M12 bolt assemblies) are delivered with the device. Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 30: Mounting Bracket Dimensions

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation Mounting Bracket Dimensions The Smart PCS mounting bracket has four groups of tapped holes, with each group containing four tapped holes. Mark any hole in each group based on site requirements and mark four holes in total.
  • Page 31 LUNA2000-100KTL-M1 Smart Power Control System User Manual 4 Installation If the bolt length does not meet the installation requirements, prepare M12 bolts and use them together with the delivered M12 nuts. Step 2 Install mounting ears. Figure 4-7 Installing mounting ears Step 3 Install the device on the mounting bracket.

  • Page 32: Electrical Connections

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Electrical Connections 5.1 Precautions Before connecting cables, ensure that the DC and AC switches on the Smart PCS and all switches connecting to it are set to the OFF position. Otherwise, the high voltage of the device may result in electric shocks.

  • Page 33: Preparing Cables

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections 5.2 Preparing Cables Table 5-1 Cable description (S: cross-sectional area of the AC cable conductor; S : cross-sectional area of the ground cable conductor) Cable Type Conductor Outer Source Cross-Sectional...

  • Page 34: Follow-Up Procedure

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections ⚫ The grounding should comply with local electrical safety regulations. ⚫ It is recommended that the Smart PCS be connected to a nearby ground point. The ground points of all Smart PCSs in the same array must be connected to ensure equipotential connections to ground cables.

  • Page 35: Opening The Dc Maintenance Compartment Door

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections ⚫ Do not open the Smart PCS panel. ⚫ Before opening the maintenance compartment door of the Smart PCS, turn off the external switches on the AC and DC sides.

  • Page 36: Opening The Ac Maintenance Compartment Door

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-3 Removing accessories from the DC maintenance compartment (1) Spare screws on the door panel of the maintenance (2) Crimping compartment module ----End 5.4.2 Opening the AC Maintenance Compartment Door Step 1 Open the AC maintenance compartment door.

  • Page 37: Replacing The Crimping Module

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-5 Removing accessories from the AC maintenance compartment (1) Spare screws on the door panel of the maintenance (2) Crimping compartment module ----End 5.5 Replacing the Crimping Module Procedure ⚫...
  • Page 38 LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-6 Replacing the crimping module (on the DC side) Figure 5-7 (Optional) Replacing the crimping module (on the AC side) ----End Follow-up Procedure Use scissors to cut off the joints of the rubber rings in order to remove them. Remove all rubber rings in the same way.

  • Page 39: Connecting Dc Power Cables

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-8 Removing the rubber ring 5.6 Connecting DC Power Cables Precautions Before connecting the DC power cables, check the following items: ⚫ Check that the DC switches between the DC side of the Smart PCS and the DC LV Panel busbar are in the OFF position.

  • Page 40: Connecting Ac Power Cables

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-9 Connecting DC power cables ----End 5.7 Connecting AC Power Cables Precautions A three-phase AC switch should be installed on the AC side of the Smart PCS. To ensure that the Smart PCS can safely disconnect itself from the power grid if an exception occurs, select a proper overcurrent protection device in compliance with local power distribution regulations.
  • Page 41 LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections ⚫ The cable outer diameter can be measured using the ruler sticker in the maintenance compartment. ⚫ Ensure that the cable jacket is in the maintenance compartment. ⚫ Ensure that the AC power cables are connected securely. Otherwise, the Smart PCS may fail to operate, or become overheated during operation due to an unreliable connection, which will damage the terminal block.

  • Page 42: Connecting Fe Communications Cables

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections ----End 5.8 Connecting FE Communications Cables Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.
  • Page 43 LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections ⚫ The Smart PCS is connected to the SmartModule through FE communications cables. Ensure that the FE ports on the two ends are connected to GE2 and GE3 of the SmartModule.
  • Page 44 LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Step 2 Insert the shielded network cable through the sealing nut, seal ring, coupling nut, and plastic housing in sequence. Figure 5-14 Waterproof RJ45 connector composition (1) Shielded plug (2) Plastic housing...
  • Page 45 LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-17 Connecting the seal ring and coupling nut Step 7 Secure the sealing nut to the plastic housing. Figure 5-18 Connecting the sealing nut Ensure that the sealing nut is secured.

  • Page 46: Closing Maintenance Compartment Doors

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections 5.9 Closing Maintenance Compartment Doors ⚫ Before closing a maintenance compartment door, check that the cables are connected correctly and securely, close the terminal block cover, and remove any dirt or other unnecessary items from the maintenance compartment.
  • Page 47 LUNA2000-100KTL-M1 Smart Power Control System User Manual 5 Electrical Connections Figure 5-21 Closing the AC maintenance compartment door ----End Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 48: Power-On Commissioning

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning Power-On Commissioning ⚫ Ensure that all the preceding items are checked and meet requirements before power-on. ⚫ The Smart PCS can be commissioned using the SmartLogger WebUI or the SUN2000 app.
  • Page 49 LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning Table 6-1 LED indicators Category Indicator Status (Blinking Fast: Description On for 0.2s and then Off for 0.2s; Blinking Slowly: On for 1s and then Off for 1s) DC indication...

  • Page 50: Checking Before Power-On

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning 6.1 Checking Before Power-On Check the items listed in the following table. In case of any nonconforming items, rectify the fault and reinstall the parts. Then check the items in the table again until all they all pass the check.

  • Page 51: Downloading The App

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning ⚫ Before turning on the AC switch between the Smart PCS and the power grid, check whether the AC voltage is within the required range using a multimeter. (See the local power grid standard.)
  • Page 52 The parameter names, value ranges, and default values are subject to change. Downloading the App SUN2000 app: Access Huawei AppGallery, search for SUN2000, and download the app installation package. Alternatively, scan one of the QR codes below to download the app installation package.

  • Page 53: App Commissioning

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning 6.4 App Commissioning Prerequisites ⚫ The DC or AC side of the Smart PCS is powered on. ⚫ Connect through a WLAN module: The WLAN module has been inserted into the USB port at the bottom of the Smart PCS.
  • Page 54 LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning Figure 6-3 Selecting a connection mode Step 2 Select the login user and enter the login password. The main menu page is displayed. Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.
  • Page 55 LUNA2000-100KTL-M1 Smart Power Control System User Manual 6 Power-On Commissioning ⚫ When you log in to the system for the first time, set the login password. To ensure account security, change the password periodically and do not forget the new password. Passwords that are left unchanged for a long period of time may become vulnerable to theft or cracking.

  • Page 56: Device Maintenance

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Device Maintenance 7.1 Routine Maintenance Maintenance Items To ensure long-term operation of Smart PCS, you are advised to perform routine maintenance as described in this chapter. When cleaning the system, connecting cables, and checking grounding reliability, power off the system and ensure that the external switches on the DC and AC sides are turned off.
  • Page 57 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Check Item Check Method Maintenance Interval caps. to 12 months. Grounding Check that ground cables are securely The first inspection must reliability connected. be performed 6 months after the initial commissioning.

  • Page 58: Powering Off The Smart Pcs

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance After cleaning is complete, reinstall the air outlet protective cover. Tighten the screws to a torque of 1.2 N·m. 7.2 Powering Off the Smart PCS Context Perform the following procedures when powering off the Smart PCS for maintenance or replacement to prevent personal injury and equipment damage.

  • Page 59: Replacing A Fan

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Figure 7-3 Powering off the Smart PCS ⚫ Do not open the panel for maintenance if the Smart PCS is emitting odor or smoke, or exhibits other obvious problems. ⚫...
  • Page 60 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Figure 7-4 Pulling out fan tray (1) Step 2 Remove the cable ties shared by the cables, unscrew the connectors, and disconnect the cables. Figure 7-5 Disconnecting cables Step 3 Pull out the fan.
  • Page 61 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Step 4 Remove cable ties from the faulty fan. ⚫ Fan 1 is faulty. Figure 7-7 Removing cable ties from fan 1 ⚫ Fan 2 is faulty. Figure 7-8 Removing cable ties from fan 2 ⚫...
  • Page 62 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Figure 7-11 Installing a new fan Step 7 Bind the fan cables. ⚫ Binding positions for fan 1 Figure 7-12 Binding the cables of fan 1 ⚫ Binding positions for fan 2 Figure 7-13 Binding the cables of fan 2 ⚫...
  • Page 63 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Figure 7-15 Pushing in the fan tray Step 9 Connect the cables correctly according to the cable labels, and then bind the cables. Figure 7-16 Binding the cables Step 10 Push the fan tray into the slot and tighten the screws.

  • Page 64: Replacing The Smart Pcs

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance 7.4 Replacing the Smart PCS Context The device enclosure is severely damaged or the device hardware is faulty due to external forces. Procedure Step 1 Deliver a shutdown command on the SUN2000 app, SmartLogger, or management system.
  • Page 65 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Step 3 Choose Monitoring > Running Param. > Grid Parameters, and set Grid code. Ensure that the grid code setting of the new Smart PCS matches the local grid code. Wait for 10s, and then go to step 4.
  • Page 66 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Figure 7-20 Energy yield calibration Step 6 Click Deployment Wizard and then click Search for Device to check cable connections and allocate addresses. Figure 7-21 Searching for devices ⚫ During the process of Search for Device, do not perform upgrade operations (such as upgrading through the app, management system, or WebUI).
  • Page 67 LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance ⚫ If an alarm is generated when the cable connection check fails, click the alarm icon to view the alarm cause and handling suggestions. After the fault is rectified, check the cable connections again.

  • Page 68: Disposing Of The Smart Pcs

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 7 Device Maintenance Figure 7-23 Deleting a device ----End 7.5 Disposing of the Smart PCS If the Smart PCS reaches the end of its service life, dispose of the device according to local regulations for the disposal of electrical equipment.

  • Page 69: Alarm Reference

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Reference Alarm severities are defined as follows: ⚫ Major: The Smart PCS is faulty or the external environment is abnormal. As a result, the output power decreases or the grid-tied power generation is stopped.
  • Page 70 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion terminals are short-circuited or connected in reverse polarity. If yes, adjust the DC bus cable connection. 2007 DC Connected in Major Cause ID = 1...
  • Page 71 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion power operator. If yes, modify the power grid undervoltage protection threshold after obtaining the consent of the local power operator. 3. If the fault persists for a...
  • Page 72 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion 3. If the fault persists for a long time, check the connection of the AC cable. 4. If the AC cable is correctly...
  • Page 73 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion actual grid frequency change temporarily. The device rate does not comply with the automatically recovers local power grid standard. after detecting that the power grid becomes normal.
  • Page 74 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion 2061 Abnormal Major Cause ID = 1 Power off the device (turn off Grounding the AC and DC switches, and 1. The neutral wire or PE...
  • Page 75 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion 2. The ambient temperature is position. high. 2. If the ventilation is poor or 3. The device is faulty. the ambient temperature exceeds the upper...
  • Page 76 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion 2. If the upgrade fails for multiple times, contact your dealer or technical support. 1. Turn off the AC and DC 2086 External Fan Major Cause ID = 1–3, corresponding...
  • Page 77 LUNA2000-100KTL-M1 Smart Power Control System User Manual 8 Alarm Reference Alarm Alarm Name Severity Possible Cause Suggestion support. 2103 AC Terminal Major Cause ID = 1 Power off the devices Temperature connected to the same DC bus 1. The AC power cable is not...

  • Page 78: Technical Data

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 9 Technical Data Technical Data Efficiency Technical Specifications LUNA2000-100KTL-M1 Maximum efficiency 98.40% DC Side Technical Specifications LUNA2000-100KTL-M1 Number of DC outputs Maximum DC voltage 1100 V Maximum DC power 123 kW Maximum DC current 215.8 A...

  • Page 79: General Specifications

    LUNA2000-100KTL-M1 Smart Power Control System User Manual 9 Technical Data Technical Specifications LUNA2000-100KTL-M1 DC surge protection Type II AC surge protection Type II Insulation resistance detection Supported Residue current monitoring unit (RCMU) Supported Overvoltage category DC II/AC III Display and Communication...
  • Page 80 LUNA2000-100KTL-M1 Smart Power Control System User Manual 9 Technical Data Technical Specifications LUNA2000-100KTL-M1 Rated AC power 100 kW Maximum apparent power 120 kVA Maximum active power 120 kW Rated AC current ⚫ 151.9 A (380 V) ⚫ 144.3 A (400 V) ⚫...

  • Page 81: A Crimping An Ot Or Dt Terminal

    LUNA2000-100KTL-M1 Smart Power Control System User Manual A Crimping an OT or DT Terminal Crimping an OT or DT Terminal Requirements for OT/DT terminals ⚫ If a copper cable is used, use copper wiring terminals. ⚫ If a copper-clad aluminum cable is used, use copper wiring terminals.
  • Page 82 LUNA2000-100KTL-M1 Smart Power Control System User Manual A Crimping an OT or DT Terminal ⚫ Do not connect aluminum wiring terminals directly to the AC or DC terminal block, as this may lead to electrochemical corrosion which affects the reliability of cable connections.
  • Page 83 LUNA2000-100KTL-M1 Smart Power Control System User Manual A Crimping an OT or DT Terminal ⚫ Avoid scratching the core wire when stripping a cable. ⚫ The cavity formed after the conductor crimp strip of the OT or DT terminal has been crimped must completely wrap around the core wires.
  • Page 84 LUNA2000-100KTL-M1 Smart Power Control System User Manual A Crimping an OT or DT Terminal Figure A-3 Crimping a DT terminal (1) Cable (2) Core (3) Heat-shrink tubing (4) DT terminal (5) Hydraulic pliers (6) Heat gun Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 85: Grid Codes

    LUNA2000-100KTL-M1 Smart Power Control System User Manual B Grid Codes Grid Codes Grid codes are subject to change, and those listed are for reference only. Set the correct grid code for the Smart PCS based on regions and application scenarios.

  • Page 86: Resetting Password

    LUNA2000-100KTL-M1 Smart Power Control System User Manual C Resetting Password Resetting Password Reset the password only when the AC power is supplied to the Smart PCS from the power grid, diesel generator, or other voltage-source PCSs. Step 1 Check that the AC and DC sides of the Smart PCS are both powered on, and indicators are steady green or blinking slowly for more than 3 minutes.

  • Page 87: D Certificate Management And Maintenance

    Preconfigured Certificate Risk Disclaimer The Huawei-issued certificates preconfigured on Huawei devices during manufacturing are mandatory identity credentials for Huawei devices. The disclaimer statements for using the certificates are as follows: Preconfigured Huawei-issued certificates are used only in the deployment phase, for establishing initial security channels between devices and the customer's network.

  • Page 88: Contact Information

    LUNA2000-100KTL-M1 Smart Power Control System User Manual E Contact Information Contact Information If you have any questions about this product, please contact us. Table E-1 Customer service contact information Region Country Email Europe France eu_inverter_support@huawei.c 0080033888888 Germany Spain Italy United Kingdom...
  • Page 89 Southern Africa 0800222900 Saudi Arabia 8001161177 Pakistan 0092512800019 Morocco 0800009900 Other countries 0020235353900 EU Representative Information: Huawei Technologies Hungary Kft. Add.: HU-1133 Budapest, Váci út 116-118., 1. Building, 6. floor. Email: hungary.reception@huawei.com Issue 01 (2022-11-10) Copyright © Huawei Technologies Co., Ltd.

  • Page 90: Acronyms And Abbreviations

    LUNA2000-100KTL-M1 Smart Power Control System User Manual F Acronyms and Abbreviations Acronyms and Abbreviations smart string energy storage system fast Ethernet gigabit Ethernet light emitting diode RCMU residual current monitoring unit Smart PCS smart power control system SACU smart array control unit...
