LUNA2000-100KTL-M1 Smart Power Control System
Quick Guide
Issue: 02
Part Number: 31500HTE
Date: 2023-01-05
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUNA2000-100KTL-M1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Huawei LUNA2000-100KTL-M1

  • Page 1 LUNA2000-100KTL-M1 Smart Power Control System Quick Guide Issue: 02 Part Number: 31500HTE Date: 2023-01-05 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 (4) DC maintenance compartment (5) LED indicator (6) Security Torx wrench (7) Protective ground point (8) Communications cable hole (9) AC power cable hole (COM) (10) USB port (USB) (11) DC power cable hole Copyright © Huawei Technologies Co., Ltd. 2023. All rights reserved.
  • Page 3: Installation Scenarios

    Smart String Energy (with lifting rope) Storage System (ESS) Notes: The LUNA2000-100KTL-M1 can be installed only on the LUNA2000-200KWH-2H1 Smart • String ESS. The crane (with lifting rope) is prepared by the customer (lifting capacity ≥ 1 t, operating •...
  • Page 4: Installation Process

    Installation Process Installing the Smart PCS 1. Install the mounting bracket.
  • Page 5: Manual Handling

    2. Install mounting ears. 3. Move the Smart PCS. Manual Handling Ensure that the lifting handles are installed to the correct screw holes. Do not install them to the mounting bracket screw holes on the top. Incorrect installation may cause device damage or personal injury.
  • Page 6: Electrical Connections

    Hoisting Do not walk under hoisted objects. Slowly and steadily hoist and position the Smart PCS to avoid bumping and damaging the device enclosure. 4. Install the Smart PCS to the mounting bracket. Electrical Connections • Remove the rubber rings according to the cable diameter range, and ensure that the crimping module is not damaged.
  • Page 7: Preparing Cables

    Do not pull the cables horizontally after they have been secured, as this may damage the wiring terminals. Preparing Cables • The cable diameters must comply with local standards. • The factors that affect cable selection include the rated current, cable type, routing mode, ambient temperature, and maximum expected line loss.
  • Page 8: Connecting The Ground Cable

    Connecting the Ground Cable • It is recommended that the Smart PCS be connected to a nearby ground point. The ground points of all Smart PCSs in the same array must be connected to ensure equipotential connections to ground cables. •...
  • Page 9: Connecting The Dc Power Cable

    Replacing the Crimping Module • Before connecting a DC power cable, replace the crimping module. To connect a multi-core AC power cable, replace the crimping module in the same way as on the DC side. The following describes how to replace the crimping module on the DC side. •...
  • Page 10 Connecting AC Power Cables Single-core Cable Connection Method...
  • Page 11 Three-core Cable Connection Method It is recommended that the stripped length of the L2 wire be 15 mm shorter than that of • the L1 or L3 wire. If a cable has a jacket, ensure that the jacket is in the maintenance compartment. •...
  • Page 12 Connecting FE Communications Cables • The Smart PCS is connected to the SmartModule through FE communications cables. Ensure that both ends are connected to GE2 and GE3 of the SmartModule. • For multiple Smart PCSs, connect all Smart PCSs in hand-in-hand mode through FE communications cables into a ring network.
  • Page 13: Checking Before Power-On

    Closing the AC/DC Maintenance Compartment Door The following describes how to close the maintenance compartment door on the DC side. The procedure for closing the maintenance compartment door on the AC side is the same. Checking Before Power-On Check Item The Smart PCS is not deformed or damaged.
  • Page 14 Check Item The DC maintenance compartment door is closed and the screws on the door are tightened. The waterproof plugs on the unused USB, COM, and FE ports are secured. Power-On Indicator Status (Blinking Fast: On for Category 0.2s and Off for 0.2s; Description Blinking Slowly: On for 1s and Off for 1s.)
  • Page 15 Before turning on the AC switch between the Smart PCS and the power grid, check whether the AC voltage is within the required range by using a multimeter. (See the local power grid standard.) 1. Turn on the AC switch between the AC side of the Smart PCS and the power grid. 2.
  • Page 16 Protect the password by changing it periodically, and keep it secure. Your password might • be stolen or cracked if it is left unchanged for extended periods. If you lose the password, the device must be restored to its factory settings. The Company will not be held liable for any losses resulting from improper password management.
  • Page 17 Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China solar.huawei.com...
