PDQ 9910 Installation

INSTALLATION
PDQ 9910
SURFACE MOUNTED RIM STRIKE
(FIRE RATED)
Installations of this RIM strike qualify as "Indoor Use Only" when not continuously exposed to an outdoor environment.
Important: The PDQ 9910 Electric Strikes should never be used as a door stop. Please install stops on frame in appropriate
locations. Ensure the exit device functions as intended for life safety concerns by verifying electric strike and exit device
compatibility. Maximum latch projection is essential to obtain full holding force.
When installed in a fail secure manner, the local Authority Having Jurisdiction shall be consulted with regard to the use of selected
panic hardware to ensure emergency exit from the secured area.
Catalog Specifications
MODE VOLTAGE CURRENT
Fail Secure 12V
Fail Secure 12V
Fail Secure 24V
Fail Secure 24V
Fail Secure 11-16V
Fail Secure = Fail Locked = FL AC = Alternating Current
Intermittent Duty = Energized less than 1 minute with 1:5 duty ratio Continuous Duty = Energized 1 minute or more
Dimensional Details
(228.6mm)
639336
DUTY
AC Intermittent
DC Continuous
AC Intermittent
DC Continuous
AC Intermittent
DC = Direct Current
1-3/4"
(44.5mm)
9" 8-1/4" 5-1/2"
(209.6mm) (139.7mm)
www.pdqlocks.com • Phone: 1.717.656.4281 • E-mail: help@pdqlocks.com
AMPS OHMS
0.33 22
0.50 22
0.64 22
0.24 89
0.32-0.50 22
3/4"
(19.0mm)
HORIZONTAL
ADJUSTMENT
MOUNTING
HOLES
1-5/8"
(42.0mm)
LOCK DOWN
HOLES
© 2024 PDQ Manufacturing
UL 294 Performance Ratings:
Access Control Line Security : Level I
Destructive Attack : Level I
Endurance : Level IV
Standby Power : Level I
MODEL WITH
LATCH MONITOR
ECN2401
R03-24AD-1
