PDQ 93203 Manual

93203 AUTOMATIC FLUSH BOLT
FOR WOOD DOOR APPLICATIONS
- NOT TO SCALE -
FRAME & SILL STRIKE
(2X) #8 X 3/4"[19.1] SCREWS

ACTIVE DOOR STRIKE

(2X) #8 X 3/4"[19.1] SCREWS
1 1/4"
[31.8]
3/8"
[9.5]
0.060" 7/8"
[1.5] [22.2]
L C
1 1/4"
[31.8]
(2X) 8-32 X 1/2"[12.7]
SCREWS
(2X) #8 X 3/4"[19.1]
SCREWS
R1/4"
1/2"
[R6.2]
[12.7]

NOTES:

INCHES
1. DIMENSIONS IN
2. BOTTOM FIRE BOLT:
THE BOTTOM FIRE BOLT WILL PROJECT DURING A FIRE.
DO NOT COVER WITH ANY EDGE MOUNTED DOOR HARDWARE.
3. ALWAYS CHECK PDQ WEBSITE FOR THE MOST RECENT
TEMPLATE REVISION AT WWW.PDQLOCKS.COM
5/16"
[7.9]
15/32"
[11.9]
STOP ON FRAME
1 3/4"
C L
DOOR
[44.5]

MORTISE

[25.4]
SQUARE
1/2"
BACKSET
[12.7]
3/4"
[19.0]
6 3/8"
[161.9]
8 1/4"
[209.6]
MORTISE
8 1/2"
[215.9]
1/4"
MORTISE
[6.4]
1/8"
[3.4]
MORTISE
1"
[25.4]
.
[MM]
MORTISE
2 1/4"
[57.2]
1 5/8"
[41.3]
1/2"
L C
[12.7]
1"
2 5/8"
[66.7]
1 1/4"
[31.7]
L C
MORTISE
2"
[50.8]
TEMPLATE: 939306
REV. 0
MORTISE
0.050"
[1.3]
MORTISE
15/16"
[23.8]
L C
TOP AND BOTTOM BOLT HEAD GUIDE
(TOP SHOWN)
(3X) #10 X 1"[25.4] SCREWS
1 9/16"
1 9/16"
[39.7]
[39.7]
MORTISE
6 1/16"
[154.0]
MORTISE
1/8"
[2.8]
MORTISE
7 1/8"
[181.0]
08-26-14
1/4"
[6.4]
1/4"
[6.4]
TOP OF DOOR
PAGE 1 OF 2
