ELECTRIC FIREPLACE
www.fireandicefireplaces.com
INSTALLATION AND OPERATION INSTRUCTIONS FOR
if the information in these instructions are not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
WARNING: This product can expose you to chemicals including
lead in the wiring, which is [are] known to the State of California
to cause birth defects of other reproductive harm. For more
information visit: www.p65warnings.ca.gov
261046
SAFETY INFORMATION
WARNING
01
EVO3620
PL36
EVO4220
PL42
EVO5020
PL50
EVO6020
PL60
REVISED - 202406
Advertisement
Table of Contents
Related Manuals for Amantii EVO3620/PL36
Summary of Contents for Amantii EVO3620/PL36
- Page 1 ELECTRIC FIREPLACE www.fireandicefireplaces.com INSTALLATION AND OPERATION INSTRUCTIONS FOR EVO3620 PL36 EVO4220 261046 PL42 EVO5020 PL50 EVO6020 PL60 SAFETY INFORMATION WARNING if the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS This section provides important safety precautions to follow when using electrical appliances to reduce the risk of fire, electrical shock, and injury. 1. Read all instructions before using this heater. 2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials at least 3 feet away from the heater to avoid burns and fire hazards. -
Page 3: Package Contents
PACKAGE CONTENTS Fireplace Remote Control Manual Glass Front Acrylic Crystals Hardware Screw Bag ELECTRICAL SPECIFICATIONS Voltage: 120VAC Rating: 1400 Watts Frequency: 60Hz... -
Page 4: Pre-Installation
PRE-INSTALLATION GROUNDING INSTRUCTIONS: Figure 1 This heater is for use on 120 volts. The cord has a plug as shown at (A) in figure 1. An adapter as shown at (C) is available for connecting three-blade grounding-type plugs to two-slot Grounding Pin receptacles. - Page 5 Do not share a socket with other appliances when using electric fireplace, please use a dedicated socket. × √ × Never use with an extension cord or relocatable power tap (outlet / power strip). electric fireplace × TOOLS REQUIRED (NOT INCLUDED) Safety goggles Phillips screwdriver Power drill...
-
Page 6: Installation (Wall Mounting)
IMPORTANT: This unit is designed to be securely attached to a wall with a fixed structure. Failure to do, so might result in personal injury and/or property damages. NOTE: Wall anchor is not needed if the bracket is to be mount directly on the studs. Model EVO3620/PL36 7.9in / 20cm 16in / 40.6cm Wall 16in / 40.6cm... - Page 7 3. Hang the fireplace on the mounting bracket. Secure the fireplace to the mounting bracket with the two screws removed in Step 1. 4. Place decorative crystals inside the fireplace. Remove the two screws next to the air outlet and save them for later use.
- Page 8 5. Put the glass front panel on the fireplace. CAUTION: Careful when handling glass to prevent injury or damage. 6. Secure the glass front to the fireplace with the screws removed in step 4.
- Page 9 Cabinet dimensions Cabinet 33.9 in / 86.1 cm 5.7 in / 14.6 cm 18.4 in / 46.7 cm EVO3620/PL36 EVO4220/PL42 39.9 in / 101.4 cm 5.7 in / 14.6 cm 18.4 in / 46.7 cm 47.9 in / 121.7 cm 5.7 in / 14.6 cm...
- Page 10 1. Remove the mounting bracket from the back of the fireplace. 2. Plug into the power supply and push the fireplace into the cabinet . 3. Use supplied screws to secure the fireplace to cabinet.
- Page 11 4. Place decorative crystals inside the fireplace. Remove the two screws next to the air outlet and save them for later use. 5. Put the glass front panel on the fireplace. CAUTION: Careful when handling glass to prevent injury or damage. Secure the glass front to the fireplace with the screws removed in step 4.
- Page 12 OPERATING INSTRUCTIONS Control Panel：This section explains the various functions and buttons on the control panel of the unit. The control panel is located on the top right corner of the unit. To control the unit, touch any button to wake up the control panel. The power button will flash, and all other buttons will light up.
- Page 13 Lock and Unlock Heater Function: Press and hold the heater button for 10 seconds. The ember bed will flash 6 times, indicating that the heater function is locked. To unlock the heater function, press and hold the heater button for 10 seconds. The ember bed will flash 6 times, indicating the heater function is unlocked.
-
Page 14: Remote Control
REMOTE CONTROL Power The Power Button turns the fireplace ON and OFF. Heater The Heater Button turns the heat ON and OFF. Press “+” or ”-” button to set the temperature. Flame The Flame Button turns the flame ON and OFF. Press “+” or ”-” button to set the flame color. -
Page 15: Battery Replacement
BATTERY REPLACEMENT The battery compartment is located on the back end of the remote control. 1. Press and slide the battery cover open. 2. Insert two 1.5V (AAA) batteries ensuring they are installed correctly with regard to the polarities (+ and -) marked on the inside of the battery compartment. 3. -
Page 16: Wifi Operation
WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart; 1. Search for “TuyaSmart life” in the APP store on your phone; download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION NOTE: Before log in TuyaSmart, Make sure the Wi-Fi signal is good and know the Wi-Fi account and password. - Page 17 Figure 1 Figure 2 Figure 3...
- Page 18 Figure 4 Figure 6 Figure 5...
-
Page 19: Maintenance
MAINTENANCE Clean the metal trim using a soft cloth, slightly dampened with citrus oil based product and buff with a clean soft cloth. DO NOT use brass polish or household cleaners as these products will damage the metal trim. Citrus oil based products can be obtained at supermarkets or hardware stores. The motors used on the fan and the flame generator assembly are pre-lubricated for extended bearing life and require no further lubrication. -
Page 20: Fcc Statement
FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause harmful interference, and (2) this device must accept any inter- ference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 21: Wiring Diagram
WIRING DIAGRAM MOTOR EMBER BED LIGHT FLAME TEMPERATURE CUT NTC CONNECTOR FUSE KEY CONNECTOR RECEIVER WiFi HEATER L INPUT N INPUT... -
Page 22: Year Limited Warranty
1 YEAR LIMITED WARRANTY Our electrical fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 1. This electric fireplace must be installed and operated at all times in accordance with the installa- tion and operating instructions furnished with the product.
