Rexing M2 Max User Manual page 20

Setup Steps:
Open the smart driving application and turn on BSD (blind spot
1.
detection). The button turns from gray to red.
Click to access the BSD setup page. Click the option Monitoring
2.
sensitivity and select the appropriate option (a default value may be
used). Monitoring sensitivity refers to the relative speed of the detected
object and the vehicle.
Click to access the BSD calibration page. You will initially see the
3.
concept and a brief introduction on the calibration page. Click Next to
access the real calibration interface, as shown below. Move the red line
up or down align with the horizon (the intersection line between the sky
and ground). Move the yellow line up or down to the interface between
the engine hood and ground. Move the green line left or right to the
focal point where the far end of the road intersects with the horizon.
Note: Sensitivity is the relative speed of the detected object and the
vehicle. The higher the speed, the essier it is to trigger an alarm.
Monitoring sensitivity
Monitor alarm type
Speed treshold
Alarm tone
Alarm area display
50km/h
18
High
Motor
Open
Open
