Lux Power Technology SNA5000WPV User Manual page 21

Table 3 Line Mode Specifications
INVERTER MODEL
Input Voltage Wavefor
Nominal Input Voltage(V)
Low Loss Voltage
Low Loss Return Voltage
High Loss Voltage
High Loss Return Voltage
Max. AC Input Voltage
Nominal Input Frequency
Max. AC Input Current(A)
Max. AC Input Power(W)
Max. AC Charging Current(A)
Rated AC Output Current(A)
Rated AC Output Power(W)
Rated AC Current of Bypass Relays(A)
Output Short Circuit Protection
Transfer Time
Output power derating:
When AC input voltage drops to 200V,
the output power will be derated.
37
SNA5000WPV SNA6000WPV
Sinusoidal(utility or generator)
230Vac
170Vac±7V(UPS); 90Vac±7V(Appliances)
180Vac±7V(UPS); 100Vac±7V(Appliances)
280Vac±7V
270Vac±7V
280Vac
50Hz/60Hz(Auto detection)
35 39.5
8000 9000
110 125
22 26.5
6000
5000
60
40
Software Protect when GridOff Discharge
Circuit Breaker Protect when GridOn Bypass
<15ms @ Single ; <30ms @ Parallel
Max inv current: 25A
Max inv current: 30A
Max inv power: 5kW Max inv power: 6kW
Table 4 Generator Mode Specifications
INVERTER MODEL
Rated GEN Voltage(V)
Rated GEN Frequency(Hz)
Rated GEN Input Current(A)
Rated GEN Input Power(W)
Rated GEN Current of Bypass Relays(A)
Table 5 Protection/General Specifications
INVERTER MODEL
Over Current/ Voltage Protection
Grid Monitoring
AC Surge Protection Type III
Safety Certification
Ingress Protection Rating
Display & Communication Interface
Warranty
Cooling Method
Topology
Noise Emission(typical)
Operating Temperature Range
Storage temperature
Humidity
Altitude
Dimension(D*W*H)mm
Net Weight
***115A@48VDC(AC), 125A@44VDC(AC), 125A@48VDC(PV)
SNA5000WPV SNA6000WPV
230
50/60
32
7370
40 60
SNA5000WPV SNA6000WPV
YES
YES
YES
NRS 097, CE
IP 20
LCD+LED, RS485/WIFI/CAN
2 Years
FAN
Transformer-less
<50dB
0℃ to 45℃ (full load)
-15℃ ~ 60℃
5% to 95% Relative Humidity(Non-condensing)
<2000m
505*330*135mm
14.5kg
38
