Lux Power Technology Eco BEAST 6000 User Manual

All-in-one ess
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Eco BEAST
All-in-One ESS
User Manual
Version: UM-AIO02001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco BEAST 6000 and is the answer not in the manual?

Questions and answers

Related Manuals for Lux Power Technology Eco BEAST 6000

Summary of Contents for Lux Power Technology Eco BEAST 6000

  • Page 1 Eco BEAST All-in-One ESS User Manual Version: UM-AIO02001...
  • Page 2 User Manual Copyright© 2024 Lux Power Technology Co., Ltd. All Rights Reserved. This manual, protected by the copyright and intellectual property rights of Lux Power Technology, may not be modified, copied, or reproduced without prior written permission. Brands and trademarks mentioned belong to their respective owners. Read carefully for product reliability and warranty eligibility.

  • Page 3: Table Of Contents

    User Manual CONTENT Information on this Manual Validity Scope Target Group Safety Instructions 1. Brief Introduction 1.1 Features of the inverter 1.2 Interface of the inverter 1.3 Packinglist 2. Installation 2.1 Preparation 2.2 Mounting the Unit 2.3 Battery Connection 2.3.1 Battery Power Cable Connection 2.3.2 Lithium Battery Connection 2.4 CT 2.5 AC Input/Output Connection...
  • Page 4 User Manual 2.11 Power ON/OFF 3. Working Modes 3.1 Offgrid modes introduction 3.2 Working modes related setting descreption 3.3 Working as a hybrid inverter 4. LCD Display and Settings 4.1 LED display 4.2 LCD display 4.3 Inverter status display 4.4 LCD settings 5.

  • Page 5: Information On This Manual

    User Manual Information on this Manual Validity This manual is valid for the following devices: ECO Beast 6000 Scope This manual provides the installation, operation and troubleshooting of this unit, please read this manual carefully before installations and operations. Target Group For qualified persons and endusers.

  • Page 6: Brief Introduction

    Home Loads Generator ECO Beast 6000 is a multifunctional, high frequency pure sine wave ECO Beast Energy Storage inverter, features: Applicable for pure off grid inverter/backup power /self-consumption/on grid situation Integrated with 2 MPPT solar charge controllers, MPPT ranges 120V~385V...

  • Page 7: Interface Of The Inverter

    User Manual 1.2 Interface of the inverter AC OUTPUT AC INPUT PVB- PVB+ LCD display PVA- PVA+ Normal Status indicator Fault/warning Status indicator Function buttons Dry contacts WiFi/GPRS Lin-ion P1--485B WIFI P2--485A CAN/RS485 MPPT485/CT Parallel Dry Port P4--CANH NO2 COM2 P5--CANL PV Switch Power on/off switch...
  • Page 8 User Manual SW button RESET button RUN LED ALM LED SOC LED DRY Contact 485 Port CAN Port Wall-bracket COM IN COM OUT Negative Positive connector connector Grounding...

  • Page 9: Packinglist

    User Manual 1.3 Packing List Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the following items in the package: Eco BEAST Off-grid Inverter User Manual Version: UM-SNAUS02001 Expansion Screw Wi-Fi Module X1 and Tube X4 ECO Hybrid inverter X1...

  • Page 10: Installation

    AC input. The recommended spec of AC breaker is 50A. Recommended AC input/AC output/GEN cable size for each inverter. Gauge Torque value Model Cable (mm2) ECO Beast 6000 10AWG 2.0Nm...
  • Page 11 Gauge Torque value Model Cable (mm2) ECO Beast 6000 1×10AWG 2.0Nm 4. Before connecting all wiring, please take off bottom cover by removing 5 screws as shown below.

  • Page 12: Mounting The Unit

    User Manual User Manual 2.2 Mounting the Unit NOTICE Consider the following points before selecting where to install: Mount on a solid surface Do not mount the inverter on flammable construction materials. For proper air circulation to dissipate heat, allow a clearance of approx. 20cm to the side and approx.

  • Page 13: Battery Connection

    2.3.2 Lithium Battery Connection If choosing lithium battery for ECO Beast 6000, please make sure the battery BMS is compatible with Luxpower inverter. Please check the compatible list in the Luxpower website.
  • Page 14 User Manual Lin-ion 120Ω P1--485B Parallel CAN/RS485 MPPT485/CT P2--485A P4--CANH P5--CANL ALM RUN BAT- RESET Inverter BAT+ 2.4 CT To measure the power imported from and exported to the grid, the CT must be installed at the service entry point in or near the main service panel. External Grid CT "function is off by default, and if you need inverter to export power to compensate the grid loads, you canset "External Grid CT "function to "Enable"...
  • Page 15 User Manual Please refer to the connection diagram for the correct positions of Grid CT and clamp the CT on the wires at the service entry point in the main service panel. The arrow on the CT is pointing to the inverter. (***Incorrectly install CT will cause The Display to show incorrect information and features of the inverter will not function correctly) If the CT is in a wrong direction, there is an option you can change the direction of the CT on your invertercall: CT Direction Reversed in Advanced Tab.

  • Page 16: Ac Input/Output Connection

    User Manual 2.5 AC Input/Output Connection CAUTION - There are two terminal blocks with “IN” and “OUT” markings. Please do NOT mis-connect input and output connectors. - Be sure to connect AC wires with correct polarity. If L and N wires are connected reversely, it may cause utility short-circuited when these inverters are worked in parallel operation.

  • Page 17: Pv Connection

    User Manual 2.6 PV Connection Please follow below steps to implement PV module connection: 1. Remove insulation sleeve 10mm for positive and negative conductors. 2. Check correct polarity of connection cable from PV modules and PV input connectors. 3. Connect positive pole ( + ) of connection cable to positive pole ( + ) of PV input connector.

  • Page 18: Integrated Two-Wire Start/Stop

    User Manual This all-in-one ess product can work with a generator and includes a dedicated Gen port for generator connection. Generator POWER AC OUT AC IN BAT- BAT+ BAT BREAKER In≥50A HOUSE Essential LOAD Double interlock switch or Dual Power Switch In ≥ 50A In≥50A Grid When properly wired and configured, the generator, if compatible with remote start, will...

  • Page 19: Generator Ac Connection

    User Manual Dry port NO2 COM2 NO1 COM1 Unit Status Condition NO2 & COM 2 NO1 & COM 1 Inverter is off and no output is powered. Open Open Power Off Battery voltage < Low DC warning Voltage Close Close Without Grid Battery voltage >...

  • Page 20: Generator Start And Stop Settings

    User Manual 2.7.4 Generator start and stop settings Using the Luxpower Monitoring Software, navigate to the “Maintenance” page where “Remote Set” will be automatically selected. Scroll to the “Generator” section and select the “Generator Charge Type” (see screenshot below). Typically, lead-acid batteries are charged based on voltage, while lithium batteries are charged based on SOC (State of Charge).

  • Page 21: Gen Boost Function

    User Manual Generator Start Conditions: The generator will start when utility fails and one of the following conditions is met: -The battery is discharged to the cut-off setting -There is a force charge request from the battery -The battery voltage or SOC is lower than the “Generator Charge Start Battery Volt/SOC”...

  • Page 22: Dry Contact Signal Control

    User Manual User Manual 2.8 Smart load Connection The Eco Beast's dedicated generator port can also connect to various smart loads, such as water heaters, in addition to generators. Smart Load POWER AC OUT AC IN BAT- BAT+ BAT BREAKER In≥50A HOUSE Essential LOAD Double interlock switch or...

  • Page 23: Ac Coupling Settings

    User Manual 2.9 AC Coupling Settings The AC Coupling setting must be enabled when connecting an existing on-grid system to the GEN port. Start SOC(%): The SOC at which the AC-coupled inverters are turned on when in off-grid mode (50% to 70% recommended). End SOC(%): The SOC at which the AC-coupled inverters are shut down when in off-grid mode (90% recommended).

  • Page 24: Parallel Function

    User Manual 2.10 Parallel function ECO Beast 6000 inverter support up to 16 units to composed single phase parallel system or three phase parallel system, for parallel system setup Step1. Cable connection: the system connection is as below: Cannot share PV input at any time!
  • Page 25 User Manual Cannot share PV input at any time! Utility Combiner Box All-in-One ESS #1 GRID LOAD BAT+ BAT- PV1+ PV1- PV2+ PV2- Load Combiner Box All-in-One ESS #2 GRID LOAD BAT+ BAT- PV1+ PV1- PV2+ PV2- GEN Combiner Box All-in-One ESS #3 GRID LOAD...
  • Page 26 User Manual Step2. Please put the CAN communication PIN to on status for the first and the end inverter No.1 No.2 No.n-1 No.n Lin-ion Lin-ion Lin-ion Lin-ion 120Ω 120Ω 120Ω 120Ω P1--485B Parallel P1--485B Parallel P1--485B Parallel P1--485B Parallel CAN/RS485 CAN/RS485 CAN/RS485 CAN/RS485...

  • Page 27: Power On/Off

    User Manual 2.11 Power ON/OFF 1.Power Switch: Controls the device power After completing the connections, please turn on the power switch. In certain emergency situations, users can turn off the power switch to cut the power. 3. Working modes 3.1 ECO Best 6000 modes introdution: AC is used to take the Bypass Mode load...
  • Page 28 User Manual PV charge the battery and PV Charge + Grid off power the load UPS Enable 230V 1. AC charge the battery from AC Input or GEN Input AC Charge 2. When the battery is power off, the AC can wake up the Load battery automatically PV + AC charge the battery...

  • Page 29: Working Modes Related Setting Descreption

    User Manual 3.2 Working Modes related setting description Situation Setting 1 Setting 2 Setting 3 Working modes and Description off grid inverter mode if P_Solar >=P_load, solar is used to take load and charge battery if P_Solar＜P_load, solar and battery take the load together, abnormal system will discharge until battery lower than the Cut Off Voltaqe/SOC...

  • Page 30: Working As A Hybrid Inverter

    User Manual 3.3 Working as a hybrid inverter. 3.3.1. ECO Beast 6000 can work as traditional off grid inverter or as a hybrid inverter. When PV and AC inputs are disabled and load is taken jointly, it functions as a traditional off-grid inverter;...
  • Page 31 User Manual 3.3.3 AC Charge function Disable: The system will not use AC to charge the battery (except Li-ion BMS set force charge flag) According to Time: During the setting time, system will use AC to charge the battery until battery full and battery will not discharge during the setting time. According to Battery Voltage: During the setting voltage, system will use AC to charge the battery if battery voltage is lower than AC Charge Start Battery Voltage and will stop when Voltage is higher than AC Charge End Battery Voltage.

  • Page 32: Lcd Display And Settings

    User Manual User Manual 4. LCD display and sittings 4.1 LED Display LED Indicator Messages Working normal Solid On Green fast: Warning Flashing slow: Firmware update Fault condition occurs Flashing in the inverter Normal Fault Renturn Down Enter...

  • Page 33: Lcd Display

    Generator information power , switch period of 1s When make settings on the ECO Beast 6000 inverter through the LCD, this area will display the AC Charge, Working mode settings Force Discharge, Charge Firstoption for setting on area those working modes.

  • Page 34: Inverter Status Display

    User Manual 4.3 Inverter Status Display Warning status, warning 29 Normal status, running status 40 Fault status, fault 21 Flash status: download percentis 33% When display'GRIDA', it means the Grid information is about AC utility, The percent When display 'GRIDB', it means the AC display on the right down corner means the information is about Gen set input load percentage...

  • Page 35: Lcd Settings

    User Manual 4.4 LCD Settings Renturn Down Enter There are four buttons on the LCD. Step for setting by the display: Step1: After touch Enter button for about 2 seconds the unit will enter setting mode. The setting icon and index will flashing. Step2: Touch UP or Down button to select setting index form 1 to Step3: Then touch Enter button to set this item Step4: Touch UP or Down button to change the settings...
  • Page 36 User Manual Run with No Battery: Step1: Choose battery type first, when no flashing, select Enter to choose Run with No battery For Lead Acid: Step1: Choose battery type first, when Lead-Acid flashing, select Enter to choose Lead-acid battery Battery Step2: Then choose battery capacity For Lithium battery Step1: Choose battery type first, when Li-ion flashing,...
  • Page 37 User Manual Totoal charge current (Iac+Ipv)setting Setting range: 0A~140A Default: 140A AC charge current setting: Setting range: Ic: Maximum 0A~140A charge current Default: 30A Generator charge current setting: Setting range: 0A~110A Default: 30A ConChr: Setting range: CV voltage 50.0-59.0Vdc setting (Only in Default: 56.4V Lead-acid battery)
  • Page 38 User Manual Totoal discharge current setting Id: Maximum Setting range: 0A~140A discharge Default: 140A current Setting Range: VOLT/SOC TEOd: Discharge control type: VOLT/SOC Setting range: VOLT: 40.0-OnGrid EOD Volt Default: 42V CutOFF: Cut off Voltage or SOC, depend SOC: 0-OnGrid EOD SoC on TEOd Default: 15%...
  • Page 39 User Manual Setting range: VOLT: Cut off Volt-58V Default: 42V Eod: Discharge end voltage or soc with grid, depend on TEOd SOC: Cut off SOC-90 Default: 15% Unity AC Input voltage range: 90Vac~280Vac AcIn: AC voltage range setting Unity AC Input voltage range: 170Vac~280Vac...
  • Page 40 User Manual AC charge setting (The setting process must enable the AC charging function, confirm the full Setting range: battery SOC value VOLT: 40.0-OnGrid EOD and set the Volt Default: 42V confirmation time period 1, 2, 3 to truly complete the AC charging function setting) Setting AC Charge time of 1...
  • Page 41 User Manual Setting Range: Feed-In Disable (default) Feed-In Enable/disable Only valid when Feed-In Enable Hybrid is enabled Maximum Feed-In percent Only valid when Feed-In is enabled Power Setting Range: 0-100% percent can be 0% (default) set larger than 100% in case of there is other generating device in the system...
  • Page 42 User Manual User Manual Setting Range: PV Off Grid Enable (default) PV Off Grid enable/disable PV Off Grid Disable Setting Range: Green Function Disable (default) Green Function Enable: When enabled, if the inverter load Power Save reading isless than 60W for Function more than 0 minutes, the enable/disable...
  • Page 43 User Manual Error Record -> Record Index ->> Record Msg: (Year: Month: Day; Hour: Min: Sec; Error code) Error/Alarm Record Alarm Record->Record Index->>Record Msg: (Year: Month: Day; Hour: Min: Sec; Alarm code) External Grid CT (Latest Version Only) Setting Range: Disable (default)/Enable CT OFFset Internal CT Offset...
  • Page 44 User Manual Generator charge setting -> chargecontrol type Setting Range: 1.VOL (default) 2.SOC Generator charge -> control type setting ->> control value Setting Range: VOL: 1. Start Voltage: 38.4-52V; 2. End Voltage: 48-59V; SOC: 1. Start Soc: 1-90%; 2. End Soc: 20-100%; This setting allows the user to enable or disable the internal neutral-ground...

  • Page 45: Monitor System For Offgrid

    User Manual 5. Monitor System for ECO Hybrid inverter Users can use wifi dongle /WLAN dongle/4G dongle (Avaiblable from 2021 March for some countries) tomonitor the energy storage system, The monitor website is: server. luxpowertek.com The APP is also available in the google play and apple APP store (Scan two code bar to download the APP).

  • Page 46: Specifications

    User Manual 6. Specifications Table 1 MPPT Mode Specifications ECO Beast 6000 INVERTER MODEL 8000(4000/4000) Max. PV Array Power (W） Rated PV Input Voltage (V) Number of Independent MPPT Inputs 100~480 PV Input Voltage Range (V) MPPT Voltage Range (V)
  • Page 47 User Manual 44.0Vdc(Settable) load < 20% Low DC Warning 20% ≤ load < 50% Warning Voltage @load<20% -1.2V Voltage(Lead Acid） load ≥ 50% Warning Voltage @load<20% -3.6V Low DC Warning Return Voltage Low DC Warning Voltage@Different load +2V load < 20% 42.0Vdc(Settable) Low DC Cut-off 20% ≤...
  • Page 48 User Manual Table 3 AC Mode Specifications INVERTER MODEL ECO Beast 6000 Input Voltage Wave for Sinusoidal(utility or generator) Nominal Input Voltage(V) 230Vac Low Loss Voltage 170Vac±7V(UPS); 90Vac±7V(Appliances) Low Loss Return Voltage 180Vac±7V(UPS); 100Vac±7V(Appliances) High Loss Voltage 280Vac±7V High Loss Return Voltage 270Vac±7V...
  • Page 49 User Manual Table 4 Generator Mode Specifications ECO Beast 6000 INVERTER MODEL Rated GEN Voltage(V) 50/60 RatedGEN Frequency(Hz) Rated GEN Input Current(A) 7370 Rated GEN Input Power(W) Table 5 Protection/General Specifications INVERTER MODEL ECO Beast 6000 OverCurrent/Voltage Protection Grid Monitoring...

  • Page 50: Trouble Shooting & Error List

    User Manual 7. Trouble shooting & Error List Code Description Trouble shooting Restart inverter, if the error still exist, contact Internal communication fault1 E000 us (DSP&M3) E002 Bat On Mos Fail Restart inverter, if the error still exist, contact us E003 CT Fail Check CAN cable connection is connected to...
  • Page 51 User Manual Check if you have choose the right battery brand Communication failure with and communication cable is right, if the warning W000 battery still exist, contact us Communication failure with Check communication cable, if the warning W003 still exist, contact us meter Inverter get battery fault info from battery BMS, restart battery, if the warning still exist,...
