4.3 Inverter Status Display

Normal status, running status 40
23
Warning Status, warning 29

4.4 LCD Settings

There are four buttons on the LCD.
Step for setting by the display:
Step1: After touch Enter button for about 2 seconds,
the unit will enter setting mode. The setting
icon and index will flashing.
Step2: Touch UP or Down button to select setting
index form 1 to 19.
Step3: Then touch Enter button to set this item.
Step4: Touch UP or Down button to change the settings.
Step5: Touch Enter to confirm the setting or Return the
setting list is as below.
Description
Index
1
Date& time
PV input mode
2
Setting Option
Setting Year/Month/day
Setting hour/minute/second
Default: S
S: two independent
Strings input
P:Same string input
for 2 MPPTs
dc: DC source input
24
