4K 60HZ HDMI WIRELESS
EXTENDER
Receiver (RX)
1
1
HDMI output
2
WiFi indicator
Macbook
3
Power indicator
4
Channel switch button
5
Signal indicator
6
Micro USB port
2
Connect with HDMI display device with HDMI
cable
a) Slow flash: waiting for connection
b) Steady on: connection succeeded
c) Quick flash: SSID Pairing mode
Transmitter
The indicator will turn blue when the power
is turned on
a) After connecting with TX, press to switch
channels
b) Press and hold 5s for SSID pairing
c) Press and hold 10s for restore factory
settings
a) Light off: no HDMI signal
b) Steady on: HDMI signal is transmitting
c) Quick flash: restore factory settings
For power input and firmware update
3
6
Receiver
WWW.TECHLY.COM
EN - 5
5
4
HDMI Display
