BL 227 EVO
9. PROBLEMS AND REMEDIES
9.1. TROUBLESHOOTING TABLE
SYMPTOM(S)
PROBABLE CAUSE(S)
An opening command is sent
continuously.
A security is active.
The (optional) loop detector
remains active.
The barrier remains
The (optional) switch is in
open.
"forced opening".
The (optional) cell is
signalling a presence
The swing-off sensor does
not signal "presence of arm".
Variable frequency drive is
faulty.
The barrier stays
Variable frequency drive is
locked or gets stuck
faulty.
while moving.
The barrier gets stuck
Power supply
and the control logic
LEDs are off.
The barrier takes a long
The closing after passage
time to close after a
timer is set for too long
vehicle has passed
CHECK(S) OR APPROPRIATE SOLUTION(S)
• Ensure the opening command is a pulse and not a continuous
command or an active "locked open" command.
• Check LD4.
• Adjust the programming if the security is not present.
• Check the detector's sensitivity and reset the loop detector to zero.
If the sensitivity setting is too high, it can cause the barrier to be
locked open.
• Check whether the LEDs on the detector are signalling a detector
or loop failure.
• Check condition of the switch.
• Check photocell alignment.
• Ensure photocells are not dirty.
• Swing-off of the arm is not properly adjusted. The sensor is
maladjusted.
• Check via a shunt on the electronic board to simulate the sensor
(refer to the wiring diagram).
• See chapter on error codes of the frequency converter (
Chap. 7.2.1.1, page 30).
• Check if the variable frequency drive ( Ref. 9, Chap. 5.4.3, page
12) is faulty: the red LED on the side of the variable frequency
drive is flashing. In this case, contact an Automatic Systems
representative.
• Check the electrical power supply at the general power supply box.
• Check that the circuit breaker ( Ref. 10, Chap. 5.4.3, page 12) is
active and that the voltage matches that specified in the technical
characteristics ( Chap. 5.3, page 9).
• Check the connection of the controls against the wiring diagram
and the correct torque of all the electrical cables and re-tighten if
necessary.
• Check the output of the 24Vdc power supply and the associated
LED.
• Check that the power supply indicator on AS1620 LD1 green is on.
• Check that LD5 and LD24 are flashing. If not, program the
processor(s).
• Check the values of the timers.
• View on:
-
the HMI
-
the OLED screen (Menu Parameters Timers)
-
Web interface (Menu Configuration Timers)
43
