BL 227 EVO

5.4.2. MECHANICAL

22
23
24
25
26
REF. DESIGNATION
Gear motor A102 SR
17
Gear motor A102 AVR (optional)
18 Sheet metal for gear
19 Analogue position sensor
20
Spiral cam for analogue sensor
21 Position stop (x2)
21

Fig. 4 - Location of components - Mechanical

19
18
17
REF. DESIGNATION
22
Bearing Ø30
23 Stop hub
Brake release lever
24
Only for barrier model
25
Spring assembly
26 Folded welded sheet metal for spring
11
20
SR
