5. DESCRIPTION

5.1. GENERAL DIMENSIONS

5.2. CONVENTIONS

SOLUTION 1
ROAD
B A
Door
Switching from one solution to another does not require additional parts.
300

Fig. 1 - Dimensions

SOLUTION 2
ROAD
A B
Door

Fig. 2 - Conventions

8
L
SOLUTION 3
ROAD
B A
Door
BL 227 EVO
SOLUTION 4
ROAD
A B
Door
