5.4. LOCATION OF COMPONENTS

5.4.1. GENERAL

3
2
1
4
5
REF. DESIGNATION
1 Reinforcing V
2 LED support (optional)
3 LED diffuser (optional)
4
Top cover
5
Lock
6
Frame assembly
7 Arm support shaft
8 Arm Ø75
6
9
10
11

Fig. 3 - Location of components - General

REF.
9
10
11
12
13
14
15
16
10
8
7
12
13
14
DESIGNATION
Variable frequency drive
Main circuit breaker
Folded welded sheet metal for spring
Control board assembly
Control board - AS1620
DIN rail
Raised base (optional)
Fixing frame
BL 227 EVO
16
15
