MM815
Motorized
Drop Down
TV Mount
Read this entire manual
before you begin.
Do not unpack
box contents
until verifying the
requirements listed
on page 2.
!
WARNING!
This product contains small parts that
can be a choking hazard. Do not let
children play with any of these small
parts! Keep children away from the
work area during installation.
!
Caution
This product is intended to be installed
by professional installation contractors,
or persons familiar with the tools and
methods required for this installation.
If you are not sure about your ability
to perform this installation, you must
contact a professional. MantelMount
is not responsible for damage or injury
caused by incorrect installation or
improper use.
!
Caution
Do not let children operate, pull on,
or hang from MantelMount.
!
Caution
Do not use this product in any way, or
for any purpose, that is not specifi cally
described in these instructions.
MantelMount is not responsible for
damage or injury caused by incorrect
installation or improper use.
INSTALLATION INSTRUCTIONS
Features Include:
Motorized Travel: From the comfort of your
couch, move the TV to the perfect viewing
position.
Smooth Operation: Solid shafts with
polymer bushings at pivot points provide
silent movement
Swivel Clutch: Swivel drive automatically
disengages to prevent damage if something
gets in the way of swiveling
Visual Temperature Sensor: Change to red
color at temperatures above 110ºF to warn
users if the fi replace is too hot for TV safety
If you need help, call 1.800.897.9755 ext.1
For missing/damaged parts or questions during installation, contact our Customer
Support team at 1.800.897.9755 ext.1 or support@mantelmount.com.
Customer satisfaction is our highest priority!
Access a PDF of this manual at MantelMount.com/FAQs/Specs and Manuals.
For more information on MantelMount patented technology visit:
www.mantelmount.com/pages/patents
Contains important safety information – please save! MantelMount.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MantelMount MM815
Summary of Contents for MantelMount MM815
- Page 1 Customer satisfaction is our highest priority! Access a PDF of this manual at MantelMount.com/FAQs/Specs and Manuals. For more information on MantelMount patented technology visit: www.mantelmount.com/pages/patents Contains important safety information – please save! MantelMount.com...
-
Page 2: Before Installation
B. If the Required Vertical Space is less than or equal to the Wall Space {24} RF Remote } x12 {11} Height, then MantelMount will fi t the wall space. Cable Ties Spacer {24} x4 Cable Ties If Mantel Depth is: MM815 Required Vertical Space is: Less than 8"... - Page 3 Questions during installation? Contact Customer Support: be installed in remote with Set Used to Set and Clear Positions. positive side facing up. Monday – Friday, 7am– 4pm PST 1.800.897. 9755 x1 or support@mantelmount.com MM815 Installation Instructions Customer Support 1.800.897.9755 x1 support@mantelmount.com...
- Page 4 STEP 1.6; otherwise skip to STEP 1.7. installing a sound bar, refer to STEP 1.8. If installing this mount with a MantelMount RB100 Recess Box, the bottom of the Vertical Brace must be 7”-10” from the bottom of If the lower VESA holes are less than 3" from the TV (or 7”...
- Page 5 However, if you want the TV higher on the wall (such as centered between the The Visual Heat Sensor turns red if the temperature If installing this mount with a MantelMount above the fi replace exceeds a safe 110° F – a visual cue mantel and ceiling) e.g.
- Page 6 Wall Plate, choose an option below that best describes your scenario and fi ll in the boxes. Minimum Distance (Step 2.2) MantelMount will clear your mantel properly. NOTE: Distance “E” below must always be at least the minimum distance in STEP 2.2...
- Page 7 STEP 3 The RB100 Recess Box provides a flush TV-to-wall storage by allowing the MantelMount center arm to fold into the wall when the TV is in the raised position. If installing the MM815 with an RB100, refer to your RB100 manual height chart for proper mounting location.
- Page 8 TV with hands and over-riding clutch. Mount is at zero degrees swivel after you recalibrate (drive the mount to the top position), then move the mount straight down. MM815 Installation Instructions Customer Support 1.800.897.9755 x1 support@mantelmount.com...
- Page 9 Cables should be long enough to accommodate the Ensure that cables do not get pinched within the Lifting Screws to the desired stopping left extension and swivel of MantelMount. Check all ranges of Arm when the TV is raised. and right positions. Tighten both motion before tightening the Cable Ties.
- Page 10 9. Drive mount to topmost position to check tilt 10. Repeat steps 2-9 until satisfi ed 11. Tighten Lock Nuts {15} x4 Top Tilt Adjustment Screw Locknut Loosen Screw for More Up Tilt MM815 Installation Instructions Customer Support 1.800.897.9755 x1 support@mantelmount.com...
- Page 11 MM815 Installation Instructions Customer Support 1.800.897.9755 x1 support@mantelmount.com...
-
Page 12: Troubleshooting Tips
SOLUTION The wall covering is It’s possible to install MantelMount by using concrete anchors (included) with the Lag Bolts {17}, PROVIDED the Mount swivels a little Manually center mount at zero degree swivel by rotating TV with hands and over-riding clutch. Mount is made of brick or stone. - Page 13 Bottom Clearance 40 MA X Max. Clearance MantelMount has three diff erent adjustments that must be made Note: As the mount lowers, first it tilts down. As it keeps after the installation is complete in order to operate properly. lowering, it normalizes, becoming vertical about 6 inches down.
