Iscanx4C-2-P; Iscanx4C-2-Q - extronics iSCAN X4C-2-P Operating Instructions Manual

Technical Data
(Scan engine)
Dimensions
Ambient temperature -20°C to +50°C
Storage temperature
Weight
Interface options
Terminal assignment
(Handheld scanner)
Use the device only with iSCANX4C-CABX connection cable. The
iSCANX4C-2-P and iSCANX4C-2-Q may only be used in the
hazardous area with iSCANPSCABR and iSCANPSCABU.

iSCANX4C-2-P:

• Light source
• LED safety
• Scan rate
• Reader
distance

iSCANX4C-2-Q:

• LED lighting
• Laser
• LED safety
• Laser safety
• Scan rate
• Reader
distance
104 x 76 x 185 mm (length x width x height)
-30°C to +70°C
200g (without connection cable)
RS232 or USB
USB cable
USB/D+ green
USB/D- white
GND black
+UB brown
9
Visible red light 630nm
LED classification acc. to DIN EN
60825-1
500 scans per second
20 to 850mm
Visible red light 630nm
Visible red light 630nm
LED classification acc. to IEC62471
Laser classification acc. to IEC60825-
1 Class 1
60 scans per second
30mm to 400mm
RS232 cable
RS232-TXD white
GND brown
+UB yellow
