7130/7130F MORTISE

Item Part No.
1 60-7030-0382-048
2 60-7100-X025-FIN
Not Available
23 81-9500-1549-FIN
60-7030-0385-XXX
42 60-7030-0473-XXX
60-7030-0391-XXX
60-7030-0393-XXX
60-0000-1159-FIN
43
60-7030-7049-FIN
81-9400-0036-FIN
45 81-9500-0562-200
*XXX = Specify RHR or LHR
Copyright © 2002-2024, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
24
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Patent pending and/or patent www.assaabloydss.com/patents.
Description
Latch Assembly 7130, 7130F
Cover
7130
7130F
Screw Packet, Cover
#8-32 x 5/16"
UFPHMS (5)
Mortise Lock Body Specify Hand*
7130-T8(F)
7130-T5(F)
7130-L5(F)
7130-L8(F)
Armored Front and Mounting Pack
Consists of the following:
Armored Front
Screw Pack
798 Strike Packet
