4400 Series with Corner Bracket
Brackets 498 and 2498
Standard Drop and Extra Drop
Installation Instructions
498 Standard Drop Bracket
Right Hand Door - RH
Left Hand Reverse - LHR
Controls with or without suffix "M" with Full Metal Cover.
NOTE: For special applications a separate door and frame preparation template is packed with these instructions. In those cases,
use this instruction sheet for installation sequence and closer adjustments only.
Function
Non-Hold Open
Hold Open*
*Hold Open arm door closers are not permitted to be installed
on fire doors.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated open-
ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with
all applicable codes and ratings.
855-557-5078 x 2 • www.accentra-assaabloy.com
Copyright © 1992, 2012, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9344-1149-010 Rev 3 05/24
Series Number
4400
4410
2498 Extra Drop Bracket
Closer Power Sizes
Multi-sized Closer power sizes 1 to 6.
Left Hand Door - LH
Right Hand Reverse - RHR
