Assa Abloy Accentra 4400 Series Installation Instructions Manual

4400 Series Slide Track Door Closer
Models 4440ST and P4440ST
Low Profile, Pull or Push Side, Non-Hold Open
Installation Instructions
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
To Determine Hand of Door:
Right Hand
Reverse
LEFT RIGHT
HAND HAND
DOOR
DOOR
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated open-
ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with
all applicable codes and ratings.
855-557-5078 x 2 • www.accentra-assaabloy.com
Copyright © 1997, 2011, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9344-0551-010 Rev 3 05/24
Pull (Hinge) Side
Push (Stop) Side
To Identify the Model:
Older models may
be stamped "1-6",
"1-4" or "2-6". They
Left Hand
can be replaced
Reverse
with a newer "1-6"
model which has
no stamp.
Standard 4400ST = 4 valves
Delayed Action 4400STDL = 5 valves
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Tools Needed
