[NAT]
NAT: Select this option to Activate/Deactivated the NAT (Network Address Translation)
function for this VC. The NAT function can be activated or deactivated per PVC basis.
Default Router: Select whether this PVC will be default router for internet data.
[Dynamic Route]
RIP (Routing Information Protocol): Select this option to specify the RIP version, including
RIP1, RIP2-B and RIP2-M. RIP2-B & RIP2-M are both sent in RIP-2 format, the difference is
that RIP2-M using Multicast and RIP2-B using Broadcast format.
RIP Direction: Select this option to specify the RIP direction. None is for disabling the RIP
function. Both means the ADSL Router will periodically send routing information and accept
routing information then incorporate into routing table. IN only means the ADSL router will only
accept but will not send RIP packet. OUT only means the ADSL router will only sent but will
not accept RIP packet.
[Multicast]
IGMP (Internet Group Multicast Protocol): It is a session-layer protocol used to establish
membership in a multicast group. The ADSL supports both IGMP version IGMP-v1 & IGMP-v2.
Select None to disable it.
Note: Every time you change one setting, you must click SAVE button once, and then
go to next setting's change.
