  • Page 1 –© 2010 Encore Electronics, Inc. All rights reserved.COVER © 2010 Encore Electronics, Inc. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective holders.

  • Page 2: Table Of Contents

    Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective holders. © 2010 Encore Electronics, Inc. All rights reserved. www.encore-usa.com...

  • Page 3: Chapter 1 Introduction

    This Quick Installation Guide tells you the brief information and steps of configuration of the ENDSL-4R5G Wireless Router / High Speed ADSL 2+ Modem. If you need more detailed information, you could find them on the user manual in the CD-ROM came with the product.
  • Page 4 Data is being transmitted in the WLAN. The WLAN connection is not activated. WPS is enabled, and is waiting for client to Blinks Green negotiate. WPS is disabled. Rear Panel The following table describes the interfaces of the device: Interface Description Wireless antenna. www.encore-usa.com...

  • Page 5: Package Contents

     Press the button and hold it for 3 or more than 3 seconds, to initialize WPS negotiation. Power switch, power on or power off the device. 1.3 Package Contents  One ENDSL-4R5G device  One DC power adapter  One splitter (optional) ...

  • Page 6: Chapter 2 Hardware Installation

    2.1 Connection with no telephone set installed before splitter Figure 1 displays the application diagram for the connection of the router, computer, splitter and the telephone sets, when no telephone set is placed before the splitter. Figure 1 Connection diagram (Without connecting telephone set before the splitter) www.encore-usa.com...

  • Page 7: Connection With Telephone Set Installed Before Splitter

    Internet access, or slow connection speed. If you really need to add a telephone set before the splitter, you must add a micro-filter before a telephone set. Do not connect several telephones before the splitter or connect several telephones with the micro-filter. www.encore-usa.com...

  • Page 8: Chapter 3 Setting Up The Tcp/Ip Properties

    DHCP client to get the IP address information automatically from the DSL router device. 3.1.1 Windows XP The following describes the operation procedures in Windows XP. Step 1 Choose Start > Control Panel > Switch to Classic View. The page as shown in the following figure appears. www.encore-usa.com...
  • Page 9 Step 2 Double-click the Network Connections icon. Step 3 Right-click the Local Area Connection icon, and then select Properties in the menu. www.encore-usa.com...
  • Page 10 Step 4 In the Local Area Connection Properties window, click the General tab, and select Internet Protocol (TCP/IP). Then click Properties. Step 5 Select Obtain an IP address automatically and Obtain DNS server address automatically. www.encore-usa.com...

  • Page 11: Windows Vista/7

    After setting, click OK. 3.1.2 Windows Vista/7 The following describes the operation procedures in Windows Vista/7 systems. Step 1 Choose Start > Control Panel. The page as shown in the following figure appears. Step 2 Double-click the Network and Sharing Center icon. www.encore-usa.com...
  • Page 12 Step 3 In the left pane, select Manage network connections, the page as shown in the following figure appears. Step 4 Right-click the icon of Local Area Connection, and then select Properties in the menu. www.encore-usa.com...
  • Page 13 Step 5 In the Local Area Connection Properties window, select Internet Protocol Version 4 (TCP/IPV4). Then click Properties. Step 6 Select Obtain an IP address automatically and Obtain DNS server address automatically. Step 7 After setting, click OK. www.encore-usa.com...

  • Page 14: Linux System

    Step 1 Select Network Connections from Preferences on System menu and the page as shown in the following figure appears. Then, select the Wired tab. Step 2 Select Auto eth0 item and click the Edit… button to edit the settings. www.encore-usa.com...
  • Page 15 Step 3 On the Edit Auto eht0 window, check the IPv4 Settings tab. Step 4 On the IPv4 Settings tab, select Automatic (DHCP) from the Method pull-down menu. www.encore-usa.com...

  • Page 16: Mac System

    Click the Ethernet connected from connections list on left side and select Using DHCP setting in Configure IPv4 option on the right side. And, you would be able to see the IP Address assignment in the same window www.encore-usa.com...

  • Page 17: Checking The Tcp/Ip Configuration

    In the Open field, enter cmd, and then click OK. Step 3 In the prompt window, enter ipconfig /all, and then press Enter. The page as shown in the following figure appears. All the Ethernet adapter information is displayed. You can check the configuration of the computer. www.encore-usa.com...

  • Page 18: Linux System

    Enter Exit, and press Enter. Then the prompt window logouts. 3.2.2 Linux System Step 1 Access the command line Terminal window from the Accessories sub-menu in the Applications menu. Step 2 Use “ifconfig” command to check the IP address assignment in the command line. www.encore-usa.com...

  • Page 19: Access The Web Configuration

    In the Web configuration page, you can click Apply Changes to save the settings temporarily. If you want to save the settings in this page permanently, click Save of Attention that appears at the bottom of the Web page after the configuration. www.encore-usa.com...

  • Page 20: Wizard

    You are recommended to change the password after login for the first time. Enter the new password twice and click Next. The page as shown in the following figure appears. In this page, you can configure the system time and Network Time Protocol (NTP) server. www.encore-usa.com...
  • Page 21 It displays the Greenwich Mean Time (GMT). After setting, click Next. The page as shown in the following figure appears. The procedure for configuring the ADSL settings of the router is as follows: Step 1 Select the country where you are from the drop-down list. www.encore-usa.com...
  • Page 22 Virtual channel identifier (VCI) is the virtual channel between two points in an ATM network. Its valid value is in the range of 32 to 65535 (0 to 31 is reserved for local management of ATM traffic). In this example, VCI is set to 100. www.encore-usa.com...
  • Page 23 Enter the password for PPPoE dial-up, which is provided by Password your ISP. Confirmed Enter the password again. Password PPPoA Select PPPoA as the protocol, the page as shown in the following figure appears. For the parameters in this page, refer to the parameter description of PPPoE protocol. www.encore-usa.com...
  • Page 24 After entering correct VPI and VCI, DHCP automatically assigns the WAN IP address, gateway and DNS information to this device. 1483 MER: Static IP Select 1483 MER: Static IP as the protocol, the page as shown in the following page appears. www.encore-usa.com...
  • Page 25 Enter the default gateway, which is provided by your ISP. Primary DNS Enter the DNS server, which is provided by your ISP. Server 1483 Bridged Select 1483 Bridged as the connection type, the page as shown in the following figure appears. www.encore-usa.com...
  • Page 26 For parameters in this page, refer to the parameter description of 1483 MER: Static IP. After setting, click Next, the page as shown in the following page appears. The following table describes the parameters in this page: Description Field www.encore-usa.com...
  • Page 27 SSID. Enter a descriptive name that is used when the wireless client connecting to the router. By default, the SSID is ENDSL-4R5G. Configure the wireless encryption mode. You can choose None, WEP, WPA (TKIP), WPA (AES), WPA2 (AES), WPA2 (TKIP), or WPA2 Mixed.
  • Page 28 Pre-Shared Key field. For the parameters of WPA (AES), WPA2 (TKIP), WPA2 (AES), and WPA2 Mixed refer to the parameter description of WPA (TKIP). After finishing the configuration, click Next. The page as shown in the following figure appears. www.encore-usa.com...

  • Page 29: Technical Support

    4.3 Technical Support For more details of product information or configuration, please check the user manual in the CD-ROM came with the product. For technical support related issues, please check the Support section on our web site http://www.encore-usa.com. www.encore-usa.com...
  • Page 30 * Local tech-support numbers are provided in selectively countries. Service may change without prior notice. Please visit www.encore-usa.com for more details. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
