Typical VLan Setup:
Fig. 4
Example
Example
vLan ID 20
vLan ID 10
for ports 5-6
for ports 1-4
USB Port for
Configuring
Pass thru
Trunk
(i.e. VLan ID 10 and/or 20)
(i.e. VLan ID 10 and 20)
Fiber to
Fiber from
Next NetWaySP82
Host Switch
- 8 -
NetWaySP8C3W Series Installation Guide
